购物车高频（RF）继电器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 线圈类型 | 线圈电流 | 线圈电压 | 触点形式 | 触点额定值（电流） | 切换电压 | 必须动作电压 | 必须释放电压 | 动作时间 | 释放时间 | 特性 | 安装类型 | 端接样式 | 工作温度 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
9002-05-02RELAY RF SPST-NC 500MA 5V Coto Technology |
1,711 |
|
规格书 |
9000 | Tube | Obsolete | Non Latching | 14.3 mA | 5VDC | SPST-NC (1 Form B) | 500 mA | 200VAC, 200VDC - Max | 3.75 VDC | 0.4 VDC | 0.35 ms | 0.1 ms | - | Through Hole | PC Pin | -20°C ~ 85°C |
|
|
9402-05-10RELAY RF SPST-NO 500MA 5V Coto Technology |
2,391 |
|
规格书 |
9400 | Tube | Obsolete | Non Latching | 25 mA | 5VDC | SPST-NO (1 Form A) | 500 mA | 200VAC, 200VDC - Max | 3.75 VDC | 0.4 VDC | 0.4 ms | 0.2 ms | - | Surface Mount | Axial | -20°C ~ 85°C |
|
9402-12-30RELAY RF SPST-NO 500MA 12V Coto Technology |
1,821 |
|
规格书 |
9400 | Tube | Obsolete | Non Latching | 14.5 mA | 12VDC | SPST-NO (1 Form A) | 500 mA | 200VAC, 200VDC - Max | 9 VDC | 1 VDC | 0.4 ms | 0.2 ms | - | Through Hole | PC Pin | -20°C ~ 85°C |
|
|
9402-12-10RELAY RF SPST-NO 500MA 12V Coto Technology |
4,932 |
|
规格书 |
9400 | Tube | Obsolete | Non Latching | 14.5 mA | 12VDC | SPST-NO (1 Form A) | 500 mA | 200VAC, 200VDC - Max | 9 VDC | 1 VDC | 0.4 ms | 0.2 ms | - | Surface Mount | Axial | -20°C ~ 85°C |
|
|
9402-05-30RELAY RF SPST-NO 500MA 5V Coto Technology |
2,199 |
|
规格书 |
9400 | Tube | Obsolete | Non Latching | 25 mA | 5VDC | SPST-NO (1 Form A) | 500 mA | 200VAC, 200VDC - Max | 3.75 VDC | 0.4 VDC | 0.4 ms | 0.2 ms | - | Through Hole | PC Pin | -20°C ~ 85°C |
|
|
9903-05-00RELAY RF SPST-NO 250MA 5V Coto Technology |
3,200 |
|
规格书 |
9900 | Tube | Obsolete | Non Latching | 33.3 mA | 5VDC | SPST-NO (1 Form A) | 250 mA | 100VAC, 100VDC - Max | 3.8 VDC | 0.4 VDC | 0.25 ms | 0.05 ms | Magnetic Shield | Surface Mount | Gull Wing | -20°C ~ 85°C |
|
|
9903-05-10RELAY RF SPST-NO 250MA 5V Coto Technology |
4,405 |
|
规格书 |
9900 | Tube | Obsolete | Non Latching | 33.3 mA | 5VDC | SPST-NO (1 Form A) | 250 mA | 100VAC, 100VDC - Max | 3.8 VDC | 0.4 VDC | 0.25 ms | 0.05 ms | Magnetic Shield | Surface Mount | Axial | -20°C ~ 85°C |
|
|
9290-12-20RELAY RF SPST-NO 500MA 12V Coto Technology |
2,361 |
|
规格书 |
9290 | Bulk | Obsolete | Non Latching | 20 mA | 12VDC | SPST-NO (1 Form A) | 500 mA | 200VAC, 200VDC - Max | 9 VDC | 1 VDC | 0.4 ms | 0.1 ms | Magnetic Shield | Surface Mount | J Lead | -20°C ~ 85°C |
|
|
9270-05-20TRRELAY RF SPST-NO 500MA 5V Coto Technology |
3,482 |
|
规格书 |
9270 | Tape & Reel (TR) | Active | Non Latching | 50 mA | 5VDC | SPST-NO (1 Form A) | 500 mA | 200VAC, 200VDC - Max | 2.5 VDC | 0.4 VDC | 0.4 ms | 0.1 ms | Magnetic Shield | Surface Mount | J Lead | -20°C ~ 125°C |
|
9202-12-00TRRELAY RF SPST-NO 500MA 12V Coto Technology |
1,718 |
|
规格书 |
9200 | Tape & Reel (TR) | Active | Non Latching | 18.5 mA | 12VDC | SPST-NO (1 Form A) | 500 mA | 200VAC, 200VDC - Max | 9 VDC | 1 VDC | 0.4 ms | 0.1 ms | Sealed - Hermetically | Surface Mount | Gull Wing | -20°C ~ 85°C |
