购物车固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRP1235-R15MFIXED IND 150NH 41A 1.2 MOHM SMD Bourns Inc. |
2,522 |
|
规格书 |
SRP1235 | Nonstandard | Tape & Reel (TR) | Obsolete | - | Iron | 150 nH | ±20% | 41 A | 50A | Shielded | 1.2mOhm Max | - | 100MHz | - | -55°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.547" L x 0.531" W (13.90mm x 13.50mm) | 0.146" (3.70mm) |
|
|
SRP1235-R22MFIXED IND 220NH 38.5A 1.3MOHM SM Bourns Inc. |
1,123 |
|
规格书 |
SRP1235 | Nonstandard | Tape & Reel (TR) | Obsolete | - | Iron | 220 nH | ±20% | 38.5 A | 50A | Shielded | 1.3mOhm Max | - | 94MHz | - | -55°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.547" L x 0.531" W (13.90mm x 13.50mm) | 0.146" (3.70mm) |
|
|
SRP1235-R60MFIXED IND 600NH 29A 2.5 MOHM SMD Bourns Inc. |
1,051 |
|
规格书 |
SRP1235 | Nonstandard | Tape & Reel (TR) | Obsolete | - | Iron | 600 nH | ±20% | 29 A | 42A | Shielded | 2.5mOhm Max | - | 73MHz | - | -55°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.547" L x 0.531" W (13.90mm x 13.50mm) | 0.146" (3.70mm) |
|
|
SRP1235-R82MFIXED IND 820NH 25A 3 MOHM SMD Bourns Inc. |
4,884 |
|
规格书 |
SRP1235 | Nonstandard | Tape & Reel (TR) | Obsolete | - | Iron | 820 nH | ±20% | 25 A | 38A | Shielded | 3mOhm Max | - | 65MHz | - | -55°C ~ 150°C | 100 kHz | - | Surface Mount | - | 0.547" L x 0.531" W (13.90mm x 13.50mm) | 0.146" (3.70mm) |
|
SRP7030-6R2FMFIXED IND 6.2UH SMD Bourns Inc. |
4,271 |
|
规格书 |
SRP7030F | Nonstandard | Tape & Reel (TR) | Active | - | Iron | 6.2 µH | ±20% | - | - | Shielded | - | - | - | - | -55°C ~ 125°C | 100 kHz | Flat Wire | Surface Mount | - | 0.299" L x 0.256" W (7.60mm x 6.50mm) | 0.126" (3.20mm) |
|
SRR1260-470YFIXED IND 47UH 2.6A 86 MOHM SMD Bourns Inc. |
1,700 |
|
规格书 |
SRR1260 | Nonstandard | Tape & Reel (TR) | Active | Drum Core, Wirewound | Ferrite | 47 µH | ±30% | 2.6 A | 2.5A | Shielded | 86mOhm Max | 22 @ 2.52MHz | 7.63MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.492" L x 0.492" W (12.50mm x 12.50mm) | 0.256" (6.50mm) |
|
CM100505-10NJLFIXED IND 10NH 320MA 410MOHM SMD Bourns Inc. |
2,690 |
|
规格书 |
CM100505 | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Alumina | 10 nH | ±5% | 320 mA | - | Unshielded | 410mOhm Max | 8 @ 100MHz | 2.8GHz | - | -40°C ~ 100°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
|
CM100505-12NJLFIXED IND 12NH 320MA 450MOHM SMD Bourns Inc. |
3,350 |
|
规格书 |
CM100505 | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Alumina | 12 nH | ±5% | 320 mA | - | Unshielded | 450mOhm Max | 8 @ 100MHz | 2.8GHz | - | -40°C ~ 100°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
|
CM100505-15NJLFIXED IND 15NH 240MA 600MOHM SMD Bourns Inc. |
3,682 |
|
规格书 |
CM100505 | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Alumina | 15 nH | ±5% | 240 mA | - | Unshielded | 600mOhm Max | 8 @ 100MHz | 2.5GHz | - | -40°C ~ 100°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
|
|
CM100505-18NJLFIXED IND 18NH 240MA 700MOHM SMD Bourns Inc. |
3,358 |
|
规格书 |
CM100505 | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Alumina | 18 nH | ±5% | 240 mA | - | Unshielded | 700mOhm Max | 8 @ 100MHz | 2.2GHz | - | -40°C ~ 100°C | 100 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.024" (0.60mm) |
