购物车固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PM42S-2R7FIXED IND 2.7UH 1.28A 105MOHM SM Bourns Inc. |
1,640 |
|
规格书 |
PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 2.7 µH | ±30% | 1.28 A | - | Shielded | 105mOhm Max | - | - | - | -30°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-390FIXED IND 39UH 300MA 709MOHM SMD Bourns Inc. |
3,975 |
|
规格书 |
PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 39 µH | ±30% | 300 mA | - | Shielded | 709mOhm Max | - | - | - | -30°C ~ 100°C | 10 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-3R3FIXED IND 3.3UH 1.04A 110MOHM SM Bourns Inc. |
1,954 |
|
规格书 |
PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 3.3 µH | ±30% | 1.04 A | - | Shielded | 110mOhm Max | - | - | - | -30°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-560FIXED IND 56UH 260MA 1.08OHM SMD Bourns Inc. |
4,844 |
|
规格书 |
PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 56 µH | ±30% | 260 mA | - | Shielded | 1.08Ohm Max | - | - | - | -30°C ~ 100°C | 10 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-5R6FIXED IND 5.6UH 800MA 170MOHM SM Bourns Inc. |
1,359 |
|
规格书 |
PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 5.6 µH | ±30% | 800 mA | - | Shielded | 170mOhm Max | - | - | - | -30°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-820FIXED IND 82UH 220MA 1.56OHM SMD Bourns Inc. |
3,266 |
|
规格书 |
PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 82 µH | ±30% | 220 mA | - | Shielded | 1.56Ohm Max | - | - | - | -30°C ~ 100°C | 10 kHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
|
PM42S-8R2FIXED IND 8.2UH 680MA 245MOHM SM Bourns Inc. |
3,252 |
|
规格书 |
PM42S | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 8.2 µH | ±30% | 680 mA | - | Shielded | 245mOhm Max | - | - | - | -30°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.189" L x 0.189" W (4.80mm x 4.80mm) | 0.079" (2.00mm) |
|
PM43-1R0MFIXED IND 1UH 2.56A 49 MOHM SMD Bourns Inc. |
1,462 |
|
规格书 |
PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 1 µH | ±20% | 2.56 A | - | Unshielded | 49mOhm | - | 113MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
|
PM43-1R4MFIXED IND 1.4UH 2.52A 57MOHM SMD Bourns Inc. |
4,554 |
|
规格书 |
PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 1.4 µH | ±20% | 2.52 A | - | Unshielded | 57mOhm | - | 101MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
|
|
PM43-1R8MFIXED IND 1.8UH 1.95A 64MOHM SMD Bourns Inc. |
1,385 |
|
规格书 |
PM43 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 1.8 µH | ±20% | 1.95 A | - | Unshielded | 64mOhm | - | 92MHz | - | -40°C ~ 100°C | 7.96 MHz | - | Surface Mount | - | 0.177" L x 0.157" W (4.50mm x 4.00mm) | 0.138" (3.50mm) |
