| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
FSLU2520-12NKP2FIXED IND 12NH 690MA 170MOHM SMD Toko America Inc. |
3,536 |
|
规格书 |
FSLU2520 | 1008 (2520 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 12 nH | ±10% | 690 mA | - | Unshielded | 170mOhm Max | 15 @ 100MHz | 2.1GHz | - | -40°C ~ 85°C | 100 MHz | - | Surface Mount | 1008 (2520 Metric) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.071" (1.80mm) |
|
|
FSLU2520-56NKP2INDUCTOR .056UH 10% TYP FSLU SMD Toko America Inc. |
1,267 |
|
规格书 |
FSLU2520 | 1008 (2520 Metric) | Cut Tape (CT) | Obsolete | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Surface Mount | 1008 (2520 Metric) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.071" (1.80mm) |
|
|
FSLU2520-R27KP2FIXED IND 270NH 420MA 380MOHM SM Toko America Inc. |
5,294 |
|
规格书 |
FSLU2520 | 1008 (2520 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 270 nH | ±10% | 420 mA | - | Unshielded | 380mOhm Max | 30 @ 25.2MHz | 425MHz | - | -40°C ~ 85°C | 25.2 MHz | - | Surface Mount | 1008 (2520 Metric) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.071" (1.80mm) |
|
|
FSLU2520-18NKP2FIXED IND 18NH 600MA 200MOHM SMD Toko America Inc. |
4,255 |
|
规格书 |
FSLU2520 | 1008 (2520 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 18 nH | ±10% | 600 mA | - | Unshielded | 200mOhm Max | 15 @ 100MHz | 1.75GHz | - | -40°C ~ 85°C | 100 MHz | - | Surface Mount | 1008 (2520 Metric) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.071" (1.80mm) |
|
|
FSLU2520-15NKP2FIXED IND 15NH 660MA 190MOHM SMD Toko America Inc. |
2,911 |
|
规格书 |
FSLU2520 | 1008 (2520 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 15 nH | ±10% | 660 mA | - | Unshielded | 190mOhm Max | 15 @ 100MHz | 2GHz | - | -40°C ~ 85°C | 100 MHz | - | Surface Mount | 1008 (2520 Metric) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.071" (1.80mm) |
|
|
FSLU2520-R18KP2FIXED IND 180NH 460MA 290MOHM SM Toko America Inc. |
2,464 |
|
规格书 |
FSLU2520 | 1008 (2520 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 180 nH | ±10% | 460 mA | - | Unshielded | 290mOhm Max | 30 @ 25.2MHz | 540MHz | - | -40°C ~ 85°C | 25.2 MHz | - | Surface Mount | 1008 (2520 Metric) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.071" (1.80mm) |
|
|
FSLU2520-R10KP2FIXED IND 100NH 380MA 530MOHM SM Toko America Inc. |
9,672 |
|
规格书 |
FSLU2520 | 1008 (2520 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 100 nH | ±10% | 380 mA | - | Unshielded | 530mOhm Max | 20 @ 100MHz | 500MHz | - | -40°C ~ 85°C | 100 MHz | - | Surface Mount | 1008 (2520 Metric) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.071" (1.80mm) |
|
|
FSLU2520-1R2JP2FIXED IND 1.2UH 235MA 950MOHM SM Toko America Inc. |
20,206 |
|
规格书 |
FSLU2520 | 1008 (2520 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 1.2 µH | ±5% | 235 mA | - | Unshielded | 950mOhm Max | 30 @ 7.96MHz | 150MHz | - | -40°C ~ 85°C | 7.96 MHz | - | Surface Mount | 1008 (2520 Metric) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.071" (1.80mm) |
|
|
FSLU2520-27NKP2FIXED IND 27NH 520MA 250MOHM SMD Toko America Inc. |
4,975 |
|
规格书 |
FSLU2520 | 1008 (2520 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 27 nH | ±10% | 520 mA | - | Unshielded | 250mOhm Max | 15 @ 100MHz | 1.4GHz | - | -40°C ~ 85°C | 100 MHz | - | Surface Mount | 1008 (2520 Metric) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.071" (1.80mm) |
|
|
FSLU2520-47NKP2FIXED IND 47NH 440MA 340MOHM SMD Toko America Inc. |
2,294 |
|
规格书 |
FSLU2520 | 1008 (2520 Metric) | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 47 nH | ±10% | 440 mA | - | Unshielded | 340mOhm Max | 20 @ 100MHz | 1GHz | - | -40°C ~ 85°C | 100 MHz | - | Surface Mount | 1008 (2520 Metric) | 0.098" L x 0.079" W (2.50mm x 2.00mm) | 0.071" (1.80mm) |
