购物车硅电容器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 电容 | 容差 | 电压 - 击穿 | ESR（等效串联电阻） | 等效串联电感 (ESL) | 应用 | 特性 | 工作温度 | 高度 | 尺寸 / 尺寸 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
911R5KCAP SILICON 1.5PF 10% SMD |
1,200 |
|
规格书 |
91 | Nonstandard SMD | Tray | Active | 1.5 pF | ±10% | - | - | - | High Stability | - | -55°C ~ 150°C | 0.007" (0.18mm) | 0.010" L x 0.010" W (0.25mm x 0.25mm) |
|
MBC50-8B12CAP SILICON 8PF 20% 50V SMD |
300 |
|
规格书 |
MBC50 | Nonstandard Chip | Tray | Active | 8 pF | ±20% | 50 V | - | - | High Stability | - | -55°C ~ 200°C | 0.179" (4.55mm) | 1.417" L x 0.512" W (36.00mm x 13.00mm) |
|
935154521410-T3TCAP SILICON 1000PF 150V 0202 |
158 |
|
规格书 |
UWSC | 0202 (0505 Metric) | Tape & Reel (TR) | Active | 1000 pF | - | 150 V | 14 mOhms | 6pH | High Stability, Vertical Silicon Cap, Wirebond | High Reliability, Low Profile | -55°C ~ 150°C | 0.005" (0.12mm) | 0.020" L x 0.020" W (0.50mm x 0.50mm) |
|
|
935155424610-T3NCAP SILICON 0.1UF 15% 11V 0402 |
467 |
|
规格书 |
ULSC | 0402 (1005 Metric) | Tape & Reel (TR) | Active | 0.1 µF | ±15% | 11 V | 500 mOhms | 100pH | High Stability | High Reliability, Low Profile | -55°C ~ 150°C | 0.017" (0.44mm) | 0.047" L x 0.028" W (1.20mm x 0.70mm) |
|
|
9122RKCAP SILICON 22PF 10% 100V SMD |
1,200 |
|
规格书 |
91 | Nonstandard Chip | Tray | Active | 22 pF | ±10% | - | - | - | High Stability | High Reliability | -55°C ~ 150°C | 0.006" (0.15mm) | 0.020" L x 0.020" W (0.51mm x 0.51mm) |
|
905R6M-14-2CAP SILICON 5.6PF 20% SMD |
2,750 |
|
规格书 |
90 | Nonstandard SMD | Tray | Active | 5.6 pF | ±20% | - | - | - | High Stability | - | -55°C ~ 150°C | 0.008" (0.20mm) | 0.030" L x 0.030" W (0.76mm x 0.76mm) |
|
SC01500912CAP SILICON 15PF 20% 100V SMD |
600 |
|
规格书 |
SC | Nonstandard Chip | Bulk | Active | 15 pF | ±20% | 100 V | - | - | High Temperature | High Reliability | -65°C ~ 200°C | 0.006" (0.15mm) | 0.012" L x 0.012" W (0.30mm x 0.30mm) |
|
|
SC99906068CAP SILICON 1000PF 20% 100V SMD |
100 |
|
规格书 |
SC | Nonstandard Chip | Bulk | Active | 1000 pF | ±20% | 100 V | - | - | High Temperature | High Reliability | -65°C ~ 200°C | 0.006" (0.15mm) | 0.068" L x 0.068" W (1.73mm x 1.73mm) |
|
|
939113733510-T3NCAP SILICON 10000PF 15% 30V 0201 |
2,615 |
|
规格书 |
BBSC | 0201 (0603 Metric) | Tape & Reel (TR) | Active | 10000 pF | ±15% | 30 V | 500 mOhms | 100pH | High Stability | High Reliability, Low Profile | -55°C ~ 150°C | 0.017" (0.44mm) | 0.031" L x 0.024" W (0.80mm x 0.60mm) |
|
|
BTD1RVFLT27N471RASMIDSERIES, 3.6V, 470PF, DSN04 |
2,886 |
|
规格书 |
RASMID™ | 01005 (0402 Metric) | Tape & Reel (TR) | Active | 470 pF | ±15% | - | - | - | - | High Reliability, Low Profile | -55°C ~ 150°C | 0.008" (0.20mm) | 0.016" L x 0.008" W (0.40mm x 0.20mm) |
|
MA4M3050CAP SILICON 50PF 200V SMD |
100 |
|
规格书 |
4M | Nonstandard Chip | Tray | Active | 50 pF | - | 200 V | - | - | - | High Reliability | -55°C ~ 200°C | 0.008" (0.20mm) | 0.021" L x 0.021" W (0.55mm x 0.55mm) |
|
906R0M-14-2CAP SILICON 6PF 20% SMD |
100 |
|
规格书 |
90 | Nonstandard Chip | Tray | Active | 6 pF | ±20% | - | - | - | High Stability | High Reliability | -55°C ~ 150°C | 0.005" (0.13mm) | 0.010" L x 0.010" W (0.25mm x 0.25mm) |
|
|
939113424610-T3NCAP SILICON 0.1UF 15% 11V 0402 |
2,001 |
|
规格书 |
BBSC | 0402 (1005 Metric) | Tape & Reel (TR) | Active | 0.1 µF | ±15% | 11 V | 500 mOhms | 100pH | High Stability | High Reliability, Low Profile | -55°C ~ 150°C | 0.017" (0.44mm) | 0.047" L x 0.028" W (1.20mm x 0.70mm) |
|
|
9010R0M-14-2CAP SILICON 10PF 20% SMD |
1,287 |
|
规格书 |
90 | Nonstandard | Tray | Active | 10 pF | ±20% | - | - | - | High Stability | - | -55°C ~ 150°C | 0.004" (0.10mm) | 0.055" L x 0.036" W (1.40mm x 0.91mm) |
|
|
9033R0M-14-3CAP SILICON 33PF 20% SMD |
1,652 |
|
规格书 |
90 | Nonstandard | Tray | Active | 33 pF | ±20% | - | - | - | High Stability | - | -55°C ~ 150°C | 0.004" (0.10mm) | 0.055" L x 0.036" W (1.40mm x 0.91mm) |
|
|
935151723510-T3NCAP SILICON 10000PF 15% 30V 0201 |
9,195 |
|
规格书 |
UBSC | 0201 (0603 Metric) | Tape & Reel (TR) | Active | 10000 pF | ±15% | 30 V | 300 mOhms | 100pH | High Stability | High Reliability, Low Profile | -55°C ~ 150°C | 0.017" (0.44mm) | 0.031" L x 0.024" W (0.80mm x 0.60mm) |
|
|
939114722410-T3SCAP SILICON 1000PF 15% 30V 0201 |
4,131 |
|
规格书 |
BBSC | 0201 (0603 Metric) | Tape & Reel (TR) | Active | 1000 pF | ±15% | 30 V | 500 mOhms | 100pH | High Stability | High Reliability, Low Profile | -55°C ~ 150°C | 0.006" (0.14mm) | 0.024" L x 0.012" W (0.60mm x 0.30mm) |
|
|
935146522310-W0TCAP SILICON 100PF 15% 150V SMD |
9,593 |
|
规格书 |
WLSC | Nonstandard Chip | Tray | Active | 100 pF | ±15% | 150 V | 50 mOhms | 50pH | High Stability, Vertical Silicon Cap, Wirebond | High Reliability, Low Profile | -55°C ~ 150°C | 0.005" (0.12mm) | 0.010" L x 0.010" W (0.25mm x 0.25mm) |
|
RFCS04024700CJTT1CAP SILICON 4.7PF 5% 25V 0402 |
2,382 |
|
规格书 |
RFCS | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | 4.7 pF | ±5% | 25 V | - | - | - | - | -55°C ~ 125°C | 0.016" (0.41mm) | 0.040" L x 0.020" W (1.02mm x 0.51mm) |
|
|
RFCS04026800CJTT1CAP SILICON 6.8PF 5% 25V 0402 |
5,132 |
|
规格书 |
RFCS | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | 6.8 pF | ±5% | 25 V | - | - | - | - | -55°C ~ 125°C | 0.016" (0.41mm) | 0.040" L x 0.020" W (1.02mm x 0.51mm) |
