| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 电容 | 容差 | 电压 - 击穿 | ESR（等效串联电阻） | 等效串联电感 (ESL) | 应用 | 特性 | 工作温度 | 高度 | 尺寸 / 尺寸 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RFCS04024700CJTWSCAP SILICON 4.7PF 25V 0402 |
3,478 |
|
规格书 |
RFCS | 0402 (1005 Metric) | Tray | Obsolete | 4.7 pF | ±5% | 25 V | - | - | - | - | -55°C ~ 125°C | 0.016" (0.41mm) | 0.040" L x 0.020" W (1.02mm x 0.51mm) |
|
|
RFCS04025000DBGWSCAP SILICON 0.5PF 50V 0402 |
7,712 |
|
规格书 |
RFCS | 0402 (1005 Metric) | Tray | Obsolete | 0.5 pF | ±0.1pF | 50 V | - | - | - | - | -55°C ~ 125°C | 0.016" (0.41mm) | 0.040" L x 0.020" W (1.02mm x 0.51mm) |
|
|
RFCS04025000DBTWSCAP SILICON 0.5PF 50V 0402 |
2,127 |
|
规格书 |
RFCS | 0402 (1005 Metric) | Tray | Obsolete | 0.5 pF | ±0.1pF | 50 V | - | - | - | - | -55°C ~ 125°C | 0.016" (0.41mm) | 0.040" L x 0.020" W (1.02mm x 0.51mm) |
|
|
RFCS04025600CJTWSCAP SILICON 5.6PF 25V 0402 |
9,502 |
|
规格书 |
RFCS | 0402 (1005 Metric) | Tray | Obsolete | 5.6 pF | ±5% | 25 V | - | - | - | - | -55°C ~ 125°C | 0.016" (0.41mm) | 0.040" L x 0.020" W (1.02mm x 0.51mm) |
|
|
RFCS04026000DBTWSCAP SILICON 0.6PF 50V 0402 |
7,126 |
|
规格书 |
RFCS | 0402 (1005 Metric) | Tray | Obsolete | 0.6 pF | ±0.1pF | 50 V | - | - | - | - | -55°C ~ 125°C | 0.016" (0.41mm) | 0.040" L x 0.020" W (1.02mm x 0.51mm) |
|
|
RFCS04026800CJTWSCAP SILICON 6.8PF 25V 0402 |
5,125 |
|
规格书 |
RFCS | 0402 (1005 Metric) | Tray | Obsolete | 6.8 pF | ±5% | 25 V | - | - | - | - | -55°C ~ 125°C | 0.016" (0.41mm) | 0.040" L x 0.020" W (1.02mm x 0.51mm) |
|
|
RFCS04027000DBTWSCAP SILICON 0.7PF 50V 0402 |
2,250 |
|
规格书 |
RFCS | 0402 (1005 Metric) | Tray | Obsolete | 0.7 pF | ±0.1pF | 50 V | - | - | - | - | -55°C ~ 125°C | 0.016" (0.41mm) | 0.040" L x 0.020" W (1.02mm x 0.51mm) |
|
|
RFCS04028000DBTWSCAP SILICON 0.8PF 50V 0402 |
9,872 |
|
规格书 |
RFCS | 0402 (1005 Metric) | Tray | Obsolete | 0.8 pF | ±0.1pF | 50 V | - | - | - | - | -55°C ~ 125°C | 0.016" (0.41mm) | 0.040" L x 0.020" W (1.02mm x 0.51mm) |
|
|
RFCS04028200CJTWSCAP SILICON 8.2PF 25V 0402 |
8,614 |
|
规格书 |
RFCS | 0402 (1005 Metric) | Tray | Obsolete | 8.2 pF | ±5% | 25 V | - | - | - | - | -55°C ~ 125°C | 0.016" (0.41mm) | 0.040" L x 0.020" W (1.02mm x 0.51mm) |
|
|
RFCS04029000DBTWSCAP SILICON 0.9PF 50V 0402 |
3,453 |
|
规格书 |
RFCS | 0402 (1005 Metric) | Tray | Obsolete | 0.9 pF | ±0.1pF | 50 V | - | - | - | - | -55°C ~ 125°C | 0.016" (0.41mm) | 0.040" L x 0.020" W (1.02mm x 0.51mm) |
|
935154634522-T3TCAP SILICON 0.022UF 15% 50V 0504 |
5,421 |
|
规格书 |
UWSC | 0504 (1210 Metric) | Tape & Reel (TR) | Active | 0.022 µF | ±15% | 50 V | 14 mOhms | 6pH | High Stability, Vertical Silicon Cap, Wirebond | High Reliability, Low Profile | -55°C ~ 150°C | 0.005" (0.12mm) | 0.049" L x 0.039" W (1.25mm x 1.00mm) |
|
|
935153521410-T3TCAP SILICON 1000PF 15% 150V 0202 |
6,750 |
|
规格书 |
UWSC | 0202 (0505 Metric) | Tape & Reel (TR) | Active | 1000 pF | ±15% | 150 V | 14 mOhms | 6pH | High Stability, Vertical Silicon Cap, Wirebond | High Reliability, Low Profile | -55°C ~ 150°C | 0.011" (0.27mm) | 0.020" L x 0.020" W (0.50mm x 0.50mm) |
|
|
935154630510-T3TCAP SILICON 10000PF 15% 50V 0303 |
7,488 |
|
规格书 |
UWSC | 0303 (0808 Metric) | Tape & Reel (TR) | Active | 10000 pF | ±15% | 50 V | 14 mOhms | 6pH | High Stability, Vertical Silicon Cap, Wirebond | High Reliability, Low Profile | -55°C ~ 150°C | 0.005" (0.12mm) | 0.031" L x 0.031" W (0.80mm x 0.80mm) |
|
MBC50-3B12CAP SILICON 3PF 20% 50V SMD |
7,188 |
|
规格书 |
MBC50 | Nonstandard Chip | Tray | Active | 3 pF | ±20% | 50 V | - | - | High Stability | - | -55°C ~ 200°C | 0.179" (4.55mm) | 1.417" L x 0.512" W (36.00mm x 13.00mm) |
|
|
MBC50-4B12CAP SILICON 4PF 20% 50V SMD |
3,475 |
|
规格书 |
MBC50 | Nonstandard Chip | Tray | Active | 4 pF | ±20% | 50 V | - | - | High Stability | - | -55°C ~ 200°C | 0.179" (4.55mm) | 1.417" L x 0.512" W (36.00mm x 13.00mm) |
|
|
MBC50-6B12CAP SILICON 6PF 20% 50V SMD |
9,815 |
|
规格书 |
MBC50 | Nonstandard Chip | Tray | Active | 6 pF | ±20% | 50 V | - | - | High Stability | - | -55°C ~ 200°C | 0.179" (4.55mm) | 1.417" L x 0.512" W (36.00mm x 13.00mm) |
|
9020RKCAP SILICON 20PF 10% SMD |
4,650 |
|
规格书 |
90 | Nonstandard SMD | Tray | Active | 20 pF | ±10% | - | - | - | High Stability | - | -55°C ~ 150°C | 0.007" (0.18mm) | 0.015" L x 0.015" W (0.38mm x 0.38mm) |
|
910R4KCAP SILICON 0.4PF 10% SMD |
7,806 |
|
规格书 |
91 | Nonstandard SMD | Tray | Active | 0.4 pF | ±10% | - | - | - | High Stability | - | -55°C ~ 150°C | 0.007" (0.18mm) | 0.010" L x 0.010" W (0.25mm x 0.25mm) |
|
|
GC84300-00SI CAPACITOR NON HERMETIC CHIP |
7,082 |
|
- |
- | Nonstandard SMD | Tray | Active | 300 pF | ±10% | 100 V | - | - | - | - | -55°C ~ 150°C | 0.007" (0.18mm) | 0.050" L x 0.050" W (1.27mm x 1.27mm) |
|
|
GC84100-00SI CAPACITOR NON HERMETIC CHIP |
9,989 |
|
- |
- | Nonstandard SMD | Tray | Active | 100 pF | ±10% | 100 V | - | - | - | - | -55°C ~ 150°C | 0.007" (0.18mm) | 0.030" L x 0.030" W (0.76mm x 0.76mm) |
