购物车固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
VSEB0630H-1R2MCAUTOMOTIVE SMD MOLDING POWER CHK CODACA |
496 |
|
规格书 |
VSEB0630H | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 1.2 µH | ±20% | 16.5 A | 16.6A | Shielded | 6.8mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | Molded Inductors, Automotive Grade Power Inductors | Surface Mount | 2-SMD | 0.262" L x 0.254" W (6.65mm x 6.45mm) | 0.118" (3.00mm) |
|
|
CSBX1060-220MSMD HIGH CURRENT POWER INDUCTOR CODACA |
397 |
|
规格书 |
CSBX1060 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 22 µH | ±20% | 4.5 A | 8.8A | Shielded | 36.3mOhm Max | - | - | AEC-Q200 | -55°C ~ 150°C | 100 kHz | High Saturation | Surface Mount | - | 0.441" L x 0.402" W (11.20mm x 10.20mm) | 0.224" (5.70mm) |
|
|
CSBL1060-220MSMD HIGH CURRENT POWER INDUCTOR CODACA |
385 |
|
规格书 |
CSBL1060 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 22 µH | ±20% | 4.5 A | 6.5A | Shielded | 36.3mOhm Max | - | - | AEC-Q200 | -50°C ~ 150°C | 100 kHz | Flat Wire, High Q Value | Surface Mount | - | 0.441" L x 0.402" W (11.20mm x 10.20mm) | 0.224" (5.70mm) |
|
|
CSBX1060-8R2MSMD HIGH CURRENT POWER INDUCTOR CODACA |
379 |
|
规格书 |
CSBX1060 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 8.2 µH | ±20% | 7.8 A | 15A | Shielded | 15.6mOhm Max | - | - | AEC-Q200 | -55°C ~ 150°C | 100 kHz | High Saturation | Surface Mount | - | 0.441" L x 0.402" W (11.20mm x 10.20mm) | 0.224" (5.70mm) |
|
|
VSEB0630H-2R2MCAUTOMOTIVE SMD MOLDING POWER CHK CODACA |
375 |
|
规格书 |
VSEB0630H | Nonstandard | Cut Tape (CT) | Active | Molded | Alloy Powder | 2.2 µH | ±20% | 12 A | 12.2A | Shielded | 9.8mOhm Max | - | - | AEC-Q200 | -55°C ~ 155°C | 100 kHz | Molded Inductors, Automotive Grade Power Inductors | Surface Mount | 2-SMD | 0.262" L x 0.254" W (6.65mm x 6.45mm) | 0.118" (3.00mm) |
|
CSAD1010-100MSMD MOLDING POWER CHOKE CODACA |
370 |
|
规格书 |
CSAD1010 | 4-SMD, J-Lead | Tape & Reel (TR) | Active | Molded | Alloy Powder | 10 µH | ±20% | 7.6 A | 9.5A | Shielded | 25mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | 4-SMD | 0.433" L x 0.378" W (11.00mm x 9.60mm) | 0.429" (10.90mm) |
|
|
CSBX1060-150MSMD HIGH CURRENT POWER INDUCTOR CODACA |
192 |
|
规格书 |
CSBX1060 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 15 µH | ±20% | 5.6 A | 10.5A | Shielded | 24mOhm Max | - | - | AEC-Q200 | -55°C ~ 150°C | 100 kHz | High Saturation | Surface Mount | - | 0.441" L x 0.402" W (11.20mm x 10.20mm) | 0.224" (5.70mm) |
|
|
CSBL1060-150MSMD HIGH CURRENT POWER INDUCTOR CODACA |
398 |
|
规格书 |
CSBL1060 | Nonstandard | Cut Tape (CT) | Active | Wirewound | Metal Composite | 15 µH | ±20% | 5.6 A | 8.7A | Shielded | 24mOhm Max | - | - | AEC-Q200 | -50°C ~ 150°C | 100 kHz | Flat Wire, High Q Value | Surface Mount | - | 0.441" L x 0.402" W (11.20mm x 10.20mm) | 0.244" (6.20mm) |
|
|
CSEB0420H-R68MSMD MOLDING POWER CHOKE CODACA |
2,000 |
|
规格书 |
CSEB0420H | Nonstandard | Cut Tape (CT) | Active | Molded | Metal Composite | 680 nH | ±20% | 10.7 A | 8.6A | Shielded | 9.6mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | - | Molded Inductors, Molding Power Choke, Soft Saturation | Surface Mount | - | 0.169" L x 0.169" W (4.30mm x 4.30mm) | 0.087" (2.20mm) |
|
|
CSEB0420H-R22MSMD MOLDING POWER CHOKE CODACA |
2,000 |
|
规格书 |
CSEB0420H | Nonstandard | Cut Tape (CT) | Active | Molded | Metal Composite | 220 nH | ±20% | 15.5 A | 16A | Shielded | 3.8mOhm Max | - | - | AEC-Q200 | -40°C ~ 125°C | - | Molded Inductors, Molding Power Choke, Soft Saturation | Surface Mount | - | 0.169" L x 0.169" W (4.30mm x 4.30mm) | 0.087" (2.20mm) |
