| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SRU5011-3R3YFIXED IND 3.3UH 1.15A 66MOHM SMD Bourns Inc. |
1,735 |
|
规格书 |
SRU5011 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 3.3 µH | ±30% | 1.15 A | 940mA | Shielded | 66mOhm | 8 @ 7.96MHz | 110MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.205" L x 0.205" W (5.20mm x 5.20mm) | 0.047" (1.20mm) |
|
|
SRU5011-470YFIXED IND 47UH 320MA 800MOHM SMD Bourns Inc. |
1,755 |
|
规格书 |
SRU5011 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 47 µH | ±30% | 320 mA | 260mA | Shielded | 800mOhm | 16 @ 2.52MHz | 25MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.205" L x 0.205" W (5.20mm x 5.20mm) | 0.047" (1.20mm) |
|
|
SRU5011-4R7YFIXED IND 4.7UH 1A 95 MOHM SMD Bourns Inc. |
2,568 |
|
规格书 |
SRU5011 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 4.7 µH | ±30% | 1 A | 820mA | Shielded | 95mOhm | 8 @ 7.96MHz | 85MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.205" L x 0.205" W (5.20mm x 5.20mm) | 0.047" (1.20mm) |
|
|
SRU5011-680YFIXED IND 68UH 260MA 1.24OHM SMD Bourns Inc. |
2,578 |
|
规格书 |
SRU5011 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 68 µH | ±30% | 260 mA | 220mA | Shielded | 1.24Ohm | 14 @ 2.52MHz | 20MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.205" L x 0.205" W (5.20mm x 5.20mm) | 0.047" (1.20mm) |
|
|
SRU5011-6R8YFIXED IND 6.8UH 820MA 130MOHM SM Bourns Inc. |
4,187 |
|
规格书 |
SRU5011 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 6.8 µH | ±30% | 820 mA | 680mA | Shielded | 130mOhm | 8 @ 7.96MHz | 70MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.205" L x 0.205" W (5.20mm x 5.20mm) | 0.047" (1.20mm) |
|
SRU6011-100YFIXED IND 10UH 1.1A 220 MOHM SMD Bourns Inc. |
4,200 |
|
规格书 |
SRU6011 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 10 µH | ±30% | 1.1 A | 720mA | Shielded | 220mOhm Max | 12 @ 2.52MHz | 45MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.256" L x 0.244" W (6.50mm x 6.20mm) | 0.049" (1.25mm) |
|
|
SRU6011-150YFIXED IND 15UH 950MA 320MOHM SMD Bourns Inc. |
3,439 |
|
规格书 |
SRU6011 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 15 µH | ±30% | 950 mA | 620mA | Shielded | 320mOhm Max | 10 @ 2.52MHz | 32MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.256" L x 0.244" W (6.50mm x 6.20mm) | 0.049" (1.25mm) |
|
|
SRU6011-1R4YFIXED IND 1.4UH 2.6A 40 MOHM SMD Bourns Inc. |
3,595 |
|
规格书 |
SRU6011 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 1.4 µH | ±30% | 2.6 A | 1.8A | Shielded | 40mOhm Max | 8 @ 7.96MHz | 140MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.256" L x 0.244" W (6.50mm x 6.20mm) | 0.049" (1.25mm) |
|
SRU6011-220YFIXED IND 22UH 800MA 390MOHM SMD Bourns Inc. |
2,660 |
|
规格书 |
SRU6011 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 22 µH | ±30% | 800 mA | 480mA | Shielded | 390mOhm Max | 10 @ 2.52MHz | 26MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.256" L x 0.244" W (6.50mm x 6.20mm) | 0.049" (1.25mm) |
|
|
SRU6011-2R7YFIXED IND 2.7UH 2.2A 62 MOHM SMD Bourns Inc. |
1,515 |
|
规格书 |
SRU6011 | Nonstandard | Tape & Reel (TR) | Obsolete | Drum Core, Wirewound | Ferrite | 2.7 µH | ±30% | 2.2 A | 1.45A | Shielded | 62mOhm Max | 8 @ 7.96MHz | 100MHz | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.256" L x 0.244" W (6.50mm x 6.20mm) | 0.049" (1.25mm) |
