| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
XFHCL4-R82MFIXED IND 820NH 31A 2.3 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 820 nH | ±20% | 31 A | 53A | Shielded | 2.3mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
|
XFHCL4-R56MFIXED IND 560NH 36A 1.6 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 560 nH | ±20% | 36 A | 55A | Shielded | 1.6mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
|
XFHCL4-7R8MFIXED IND 7.8UH 10A 21 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 7.8 µH | ±20% | 10 A | 18A | Shielded | 21mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
|
XFHCL4-R47MFIXED IND 470NH 38A 1.3 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 470 nH | ±20% | 38 A | 65A | Shielded | 1.3mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
|
XFHCL4-6R8MFIXED IND 6.8UH 11A 19 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 6.8 µH | ±20% | 11 A | 21A | Shielded | 19mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
|
XFHCL4-1R0MFIXED IND 1UH 29A 2.65 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 1 µH | ±20% | 29 A | 50A | Shielded | 2.65mOhm Max | 24 @ 100kHz | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
|
XFHCL4-1R2MFIXED IND 1.2UH 25A 3.5 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 1.2 µH | ±20% | 25 A | 49A | Shielded | 3.5mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
|
XFHCL4-8R2MFIXED IND 8.2UH 9A 22.5 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 8.2 µH | ±20% | 9 A | 18A | Shielded | 22.5mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
|
XFHCL4-2R2MFIXED IND 2.2UH 20A 5.5 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 2.2 µH | ±20% | 20 A | 32A | Shielded | 5.5mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
|
XFHCL4-R22MFIXED IND 220NH 51A 0.8 MOHM SMD XFMRS |
250 |
|
规格书 |
XFHCL4 | - | Tape & Reel (TR) | Active | Molded | - | 220 nH | ±20% | 51 A | 80A | Shielded | 0.8mOhm Max | - | - | AEC-Q200 | -55°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.531" L x 0.504" W (13.50mm x 12.80mm) | 0.197" (5.00mm) |
