购物车固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HM66-60120LFTR13FIXED IND 12UH 1.55A 70 MOHM SMD TT Electronics/BI Magnetics |
5,776 |
|
规格书 |
HM66 | Nonstandard | Tape & Reel (TR) | Discontinued at Digi-Key | Wirewound | - | 12 µH | ±20% | 1.55 A | - | Shielded | 70mOhm Max | - | - | - | -40°C ~ 125°C | 10 kHz | - | Surface Mount | - | 0.264" L x 0.264" W (6.70mm x 6.70mm) | 0.118" (3.00mm) |
|
HM66-50680LFTR13FIXED IND 68UH 520MA 355MOHM SMD TT Electronics/BI Magnetics |
3,984 |
|
规格书 |
HM66 | Nonstandard | Tape & Reel (TR) | Discontinued at Digi-Key | Wirewound | - | 68 µH | ±20% | 520 mA | - | Shielded | 355mOhm Max | - | - | - | -40°C ~ 125°C | 10 kHz | - | Surface Mount | - | 0.224" L x 0.224" W (5.70mm x 5.70mm) | 0.118" (3.00mm) |
|
|
HM66-50100LFTR13FIXED IND 10UH 1.3A 65 MOHM SMD TT Electronics/BI Magnetics |
1,064 |
|
规格书 |
HM66 | Nonstandard | Cut Tape (CT) | Discontinued at Digi-Key | Wirewound | - | 10 µH | ±20% | 1.3 A | - | Shielded | 65mOhm Max | - | - | - | -40°C ~ 125°C | 10 kHz | - | Surface Mount | - | 0.224" L x 0.224" W (5.70mm x 5.70mm) | 0.118" (3.00mm) |
|
HM72E-121R5HLFTR13FIXED IND 1.5UH 27A 3 MOHM SMD TT Electronics/BI Magnetics |
800 |
|
- |
HM72E-12 | Nonstandard | Tape & Reel (TR) | Discontinued at Digi-Key | Molded | - | 1.5 µH | ±20% | 27 A | 27A | Unshielded | 3mOhm Max | - | - | - | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.549" L x 0.512" W (13.95mm x 13.00mm) | 0.256" (6.50mm) |
|
HA72E-06R47LFTR13FIXED IND 470NH 16.1A 4.2MOHM SM TT Electronics/BI Magnetics |
3,680 |
|
规格书 |
HA72E-06 | 2-SMD | Tape & Reel (TR) | Discontinued at Digi-Key | Molded | - | 470 nH | ±20% | 16.1 A | 19A | Unshielded | 4.2mOhm Max | - | - | AEC-Q200 | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.285" L x 0.268" W (7.23mm x 6.80mm) | 0.118" (3.00mm) |
|
|
HA72E-06R10LFTR13FIXED IND 100NH 26.2A 1.7 MOHM TT Electronics/BI Magnetics |
1,925 |
|
规格书 |
HA72E-06 | 2-SMD | Cut Tape (CT) | Discontinued at Digi-Key | Molded | - | 100 nH | ±20% | 26.2 A | 45A | Unshielded | 1.7mOhm Max | - | - | AEC-Q200 | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.285" L x 0.268" W (7.23mm x 6.80mm) | 0.118" (3.00mm) |
|
|
HA72E-061R5LFTR13FIXED IND 1.5UH 8.4A 14 MOHM SMD TT Electronics/BI Magnetics |
1,915 |
|
规格书 |
HA72E-06 | 2-SMD | Cut Tape (CT) | Discontinued at Digi-Key | Molded | - | 1.5 µH | ±20% | 8.4 A | 10A | Unshielded | 14mOhm Max | - | - | AEC-Q200 | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.285" L x 0.268" W (7.23mm x 6.80mm) | 0.118" (3.00mm) |
|
|
HA72E-061R0LFTR13FIXED IND 1UH 10.3A 10 MOHM SMD TT Electronics/BI Magnetics |
1,099 |
|
规格书 |
HA72E-06 | 2-SMD | Cut Tape (CT) | Discontinued at Digi-Key | Molded | - | 1 µH | ±20% | 10.3 A | 15A | Unshielded | 10mOhm Max | - | - | AEC-Q200 | -40°C ~ 155°C | 100 kHz | - | Surface Mount | - | 0.285" L x 0.268" W (7.23mm x 6.80mm) | 0.118" (3.00mm) |
|
HM72B-066R8LFTR13FIXED IND 6.8UH 4.1A 68 MOHM SMD TT Electronics/BI Magnetics |
2,395 |
|
规格书 |
HM72B | Nonstandard | Cut Tape (CT) | Discontinued at Digi-Key | Molded | - | 6.8 µH | ±20% | 4.1 A | 8A | Unshielded | 68mOhm Max | - | - | - | -40°C ~ 130°C | 100 kHz | - | Surface Mount | - | 0.285" L x 0.268" W (7.23mm x 6.80mm) | 0.118" (3.00mm) |
|
|
HM72B-06R15LFTR13FIXED IND 150NH 23.3A 2.5 MOHM TT Electronics/BI Magnetics |
1,822 |
|
规格书 |
HM72B | Nonstandard | Cut Tape (CT) | Discontinued at Digi-Key | Molded | - | 150 nH | ±20% | 23.3 A | 52A | Unshielded | 2.5mOhm Max | - | - | - | -40°C ~ 130°C | 100 kHz | - | Surface Mount | - | 0.285" L x 0.268" W (7.23mm x 6.80mm) | 0.118" (3.00mm) |
