购物车固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
HPL1005-10NFIXED IND 10NH 300MA 1.4 OHM SMD Susumu |
2,483 |
|
规格书 |
HPL | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Thin Film | - | 10 nH | ±2% | 300 mA | - | Unshielded | 1.4Ohm Max | 10 @ 300MHz | 3.5GHz | - | - | 300 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.013" (0.33mm) |
|
|
HPL1005-12NFIXED IND 12NH 270MA 1.65OHM SMD Susumu |
3,953 |
|
规格书 |
HPL | 0402 (1005 Metric) | Tape & Reel (TR) | Obsolete | Thin Film | - | 12 nH | ±2% | 270 mA | - | Unshielded | 1.65Ohm Max | 10 @ 300MHz | 3.5GHz | - | - | 300 MHz | - | Surface Mount | 0402 (1005 Metric) | 0.039" L x 0.020" W (1.00mm x 0.50mm) | 0.013" (0.33mm) |
|
HPL0603-1N0FIXED IND 1NH 510MA 240 MOHM SMD Susumu |
3,314 |
|
规格书 |
HPL | 0201 (0603 Metric) | Tape & Reel (TR) | Obsolete | Thin Film | - | 1 nH | ±0.2nH | 510 mA | - | Unshielded | 240mOhm Max | 10 @ 300MHz | 10GHz | - | - | 500 MHz | - | Surface Mount | 0201 (0603 Metric) | 0.024" L x 0.012" W (0.60mm x 0.30mm) | 0.013" (0.33mm) |
|
TFL0816-2N2FIXED IND 2.2NH 800MA 150MOHM SM Susumu |
3,711 |
|
规格书 |
TFL | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Thin Film | - | 2.2 nH | ±0.2nH | 800 mA | - | Unshielded | 150mOhm Max | 20 @ 300MHz | 6GHz | - | - | 200 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | 0.022" (0.55mm) |
|
|
TFL0816-3N9FIXED IND 3.9NH 700MA 200MOHM SM Susumu |
3,616 |
|
规格书 |
TFL | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Thin Film | - | 3.9 nH | ±0.2nH | 700 mA | - | Unshielded | 200mOhm Max | 20 @ 300MHz | 6GHz | - | - | 200 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | 0.022" (0.55mm) |
|
|
TFL0816-4N7FIXED IND 4.7NH 600MA 250MOHM SM Susumu |
1,948 |
|
规格书 |
TFL | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Thin Film | - | 4.7 nH | ±0.2nH | 600 mA | - | Unshielded | 250mOhm Max | 20 @ 300MHz | 5GHz | - | - | 200 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | 0.022" (0.55mm) |
|
|
TFL0816-5N6FIXED IND 5.6NH 400MA 500MOHM SM Susumu |
1,890 |
|
规格书 |
TFL | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Thin Film | - | 5.6 nH | ±0.2nH | 400 mA | - | Unshielded | 500mOhm Max | 15 @ 300MHz | 5GHz | - | - | 200 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | 0.022" (0.55mm) |
|
|
TFL0816-6N8FIXED IND 6.8NH 400MA 500MOHM SM Susumu |
2,609 |
|
规格书 |
TFL | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Thin Film | - | 6.8 nH | ±0.2nH | 400 mA | - | Unshielded | 500mOhm Max | 15 @ 300MHz | 5GHz | - | - | 200 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | 0.022" (0.55mm) |
|
|
TFL0816-8N2FIXED IND 8.2NH 400MA 500MOHM SM Susumu |
2,375 |
|
规格书 |
TFL | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Thin Film | - | 8.2 nH | ±0.2nH | 400 mA | - | Unshielded | 500mOhm Max | 15 @ 300MHz | 4GHz | - | - | 200 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | 0.022" (0.55mm) |
|
|
TFL0816-12NFIXED IND 12NH 300MA 1 OHM SMD Susumu |
3,049 |
|
规格书 |
TFL | 0603 (1608 Metric) | Tape & Reel (TR) | Obsolete | Thin Film | - | 12 nH | ±2% | 300 mA | - | Unshielded | 1Ohm Max | 15 @ 300MHz | 3GHz | - | - | 200 MHz | - | Surface Mount | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | 0.022" (0.55mm) |
