购物车固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
29683CFIXED IND 68UH 650MA 250MOHM SMD Murata Power Solutions Inc. |
2,609 |
|
规格书 |
2900 | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | Wirewound | - | 68 µH | - | 650 mA | - | Shielded | 250mOhm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - | 0.283" L x 0.283" W (7.20mm x 7.20mm) | 0.157" (4.00mm) |
|
|
29684CFIXED IND 680UH 210MA 2.4OHM SMD Murata Power Solutions Inc. |
3,451 |
|
规格书 |
2900 | Nonstandard, Corner Terminals | Tape & Reel (TR) | Active | Wirewound | - | 680 µH | - | 210 mA | - | Shielded | 2.4Ohm Max | - | - | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - | 0.283" L x 0.283" W (7.20mm x 7.20mm) | 0.157" (4.00mm) |
|
48150SCFIXED IND 15UH 3.7A 40 MOHM SMD Murata Power Solutions Inc. |
4,307 |
|
规格书 |
4800S | Nonstandard, 4 Lead | Tape & Reel (TR) | Active | Wirewound | - | 15 µH | ±20% | 3.7 A | - | Shielded | 40mOhm Max | 31 @ 1MHz | 17MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - | 0.480" L x 0.480" W (12.20mm x 12.20mm) | 0.236" (6.00mm) |
|
|
483R3SCFIXED IND 3.3UH 7.3A 12MOHM SMD Murata Power Solutions Inc. |
3,541 |
|
规格书 |
4800S | Nonstandard, 4 Lead | Tape & Reel (TR) | Active | Wirewound | - | 3.3 µH | ±30% | 7.3 A | - | Shielded | 12mOhm Max | 34 @ 1MHz | 39MHz | - | -40°C ~ 85°C | 10 kHz | - | Surface Mount | - | 0.480" L x 0.480" W (12.20mm x 12.20mm) | 0.236" (6.00mm) |
|
46684CFIXED IND 680UH 320MA 3.9OHM SMD Murata Power Solutions Inc. |
3,058 |
|
规格书 |
4600 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 680 µH | ±20% | 320 mA | - | Shielded | 3.9Ohm Max | - | - | - | -40°C ~ 125°C | 10 kHz | - | Surface Mount | - | 0.287" L x 0.287" W (7.30mm x 7.30mm) | 0.179" (4.55mm) |
|
45281CFIXED IND 280NH 8A 9 MOHM SMD Murata Power Solutions Inc. |
4,044 |
|
规格书 |
4500 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 280 nH | ±30% | 8 A | - | Shielded | 9mOhm Max | - | - | - | -40°C ~ 125°C | 10 kHz | - | Surface Mount | - | 0.287" L x 0.287" W (7.30mm x 7.30mm) | 0.140" (3.55mm) |
|
|
45541CFIXED IND 540NH 7A 11 MOHM SMD Murata Power Solutions Inc. |
1,080 |
|
规格书 |
4500 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 540 nH | ±30% | 7 A | - | Shielded | 11mOhm Max | - | - | - | -40°C ~ 125°C | 10 kHz | - | Surface Mount | - | 0.287" L x 0.287" W (7.30mm x 7.30mm) | 0.140" (3.55mm) |
|
23S101CFIXED IND 100UH 370MA 782MOHM SM Murata Power Solutions Inc. |
4,951 |
|
规格书 |
2300 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 100 µH | - | 370 mA | - | Shielded | 782mOhm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.244" L x 0.220" W (6.20mm x 5.60mm) | 0.126" (3.20mm) |
|
|
23S120CFIXED IND 12UH 1.08A 107MOHM SMD Murata Power Solutions Inc. |
4,166 |
|
规格书 |
2300 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 12 µH | - | 1.08 A | - | Shielded | 107mOhm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.244" L x 0.220" W (6.20mm x 5.60mm) | 0.126" (3.20mm) |
|
|
23S150CFIXED IND 15UH 960MA 131MOHM SMD Murata Power Solutions Inc. |
4,975 |
|
规格书 |
2300 | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 15 µH | - | 960 mA | - | Shielded | 131mOhm Max | - | - | - | -40°C ~ 85°C | 1 kHz | - | Surface Mount | - | 0.244" L x 0.220" W (6.20mm x 5.60mm) | 0.126" (3.20mm) |
