购物车直流无刷风扇（BLDC）
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 宽度 | 气流 | 静压 | 轴承类型 | 风扇类型 | 特性 | 噪音 | 功率（瓦特） | 转速（RPM） | 端接方式 | 防护等级 | 工作温度 | 认证机构 | 重量 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
3615RL-04W-B39-E50FAN AXIAL 92X38.4MM 12VDC WIRE |
4,570 |
|
规格书 |
3615RL | Box | Obsolete | 12VDC | Square - 92mm L x 92mm H | 38.40mm | 103.8 CFM (2.91m³/min) | 0.571 in H2O (142.2 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 52.5dB(A) | 9.6 W | 5000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-04W-B49-B50FAN AXIAL 92X38.4MM 12VDC WIRE |
3,446 |
|
规格书 |
3615RL | Box | Obsolete | 12VDC | Square - 92mm L x 92mm H | 38.40mm | 118.6 CFM (3.32m³/min) | 0.751 in H2O (187.0 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 56.5dB(A) | 13.8 W | 5700 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-04W-B49-E50FAN AXIAL 92X38.4MM 12VDC WIRE |
2,521 |
|
规格书 |
3615RL | Box | Obsolete | 12VDC | Square - 92mm L x 92mm H | 38.40mm | 118.6 CFM (3.32m³/min) | 0.751 in H2O (187.0 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 56.5dB(A) | 13.8 W | 5700 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-04W-B59-B50FAN AXIAL 92X38.4MM 12VDC WIRE |
1,269 |
|
规格书 |
3615RL | Box | Obsolete | 12VDC | Square - 92mm L x 92mm H | 38.40mm | 129.9 CFM (3.64m³/min) | 0.890 in H2O (221.7 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 59.0dB(A) | 17.5 W | 6200 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-04W-B59-E50FAN AXIAL 92X38.4MM 12VDC WIRE |
1,783 |
|
规格书 |
3615RL | Box | Obsolete | 12VDC | Square - 92mm L x 92mm H | 38.40mm | 129.9 CFM (3.64m³/min) | 0.890 in H2O (221.7 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 59.0dB(A) | 17.5 W | 6200 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-04W-B69-B50FAN AXIAL 92X38.4MM 12VDC WIRE |
4,109 |
|
规格书 |
3615RL | Box | Obsolete | 12VDC | Square - 92mm L x 92mm H | 38.40mm | 141.2 CFM (3.95m³/min) | 1.044 in H2O (260.0 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 61.0dB(A) | 24 W | 6700 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-04W-B69-E50FAN AXIAL 92X38.4MM 12VDC WIRE |
2,194 |
|
规格书 |
3615RL | Box | Obsolete | 12VDC | Square - 92mm L x 92mm H | 38.40mm | 141.2 CFM (3.95m³/min) | 1.044 in H2O (260.0 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 61.0dB(A) | 24 W | 6700 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-04W-B79-E50FAN AXIAL 92X38.4MM 12VDC WIRE |
1,643 |
|
规格书 |
3615RL | Box | Obsolete | 12VDC | Square - 92mm L x 92mm H | 38.40mm | 152.5 CFM (4.27m³/min) | 1.200 in H2O (298.9 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 62.5dB(A) | 28.9 W | 7200 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-05W-B39-B50FAN AXIAL 92X38.4MM 24VDC WIRE |
4,633 |
|
规格书 |
3615RL | Box | Obsolete | 24VDC | Square - 92mm L x 92mm H | 38.40mm | 103.8 CFM (2.91m³/min) | 0.571 in H2O (142.2 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 52.5dB(A) | 9.6 W | 5000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-05W-B39-E50FAN AXIAL 92X38.4MM 24VDC WIRE |
1,240 |
|
规格书 |
3615RL | Box | Obsolete | 24VDC | Square - 92mm L x 92mm H | 38.40mm | 103.8 CFM (2.91m³/min) | 0.571 in H2O (142.2 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 52.5dB(A) | 9.6 W | 5000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-05W-B49-B50FAN AXIAL 92X38.4MM 24VDC WIRE |
3,298 |
|
规格书 |
3615RL | Box | Obsolete | 24VDC | Square - 92mm L x 92mm H | 38.40mm | 118.6 CFM (3.32m³/min) | 0.751 in H2O (187.0 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 56.5dB(A) | 13.4 W | 5700 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-05W-B49-E50FAN AXIAL 92X38.4MM 24VDC WIRE |
3,773 |
|
规格书 |
3615RL | Box | Obsolete | 24VDC | Square - 92mm L x 92mm H | 38.40mm | 118.6 CFM (3.32m³/min) | 0.751 in H2O (187.0 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 56.5dB(A) | 13.4 W | 5700 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-05W-B59-B50FAN AXIAL 92X38.4MM 24VDC WIRE |
3,971 |
|
规格书 |
3615RL | Box | Obsolete | 24VDC | Square - 92mm L x 92mm H | 38.40mm | 129.9 CFM (3.64m³/min) | 0.890 in H2O (221.7 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 59.0dB(A) | 17 W | 6200 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-05W-B59-E50FAN AXIAL 92X38.4MM 24VDC WIRE |
3,535 |
|
规格书 |
3615RL | Box | Obsolete | 24VDC | Square - 92mm L x 92mm H | 38.40mm | 129.9 CFM (3.64m³/min) | 0.890 in H2O (221.7 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 59.0dB(A) | 17 W | 6200 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-05W-B69-B50FAN AXIAL 92X38.4MM 24VDC WIRE |
4,762 |
|
规格书 |
3615RL | Box | Obsolete | 24VDC | Square - 92mm L x 92mm H | 38.40mm | 141.2 CFM (3.95m³/min) | 1.044 in H2O (260.0 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 61.0dB(A) | 22.1 W | 6700 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-05W-B69-E50FAN AXIAL 92X38.4MM 24VDC WIRE |
4,208 |
|
规格书 |
3615RL | Box | Obsolete | 24VDC | Square - 92mm L x 92mm H | 38.40mm | 141.2 CFM (3.95m³/min) | 1.044 in H2O (260.0 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 61.0dB(A) | 22.1 W | 6700 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-05W-B79-E50FAN AXIAL 92X38.4MM 24VDC WIRE |
1,752 |
|
规格书 |
3615RL | Box | Obsolete | 24VDC | Square - 92mm L x 92mm H | 38.40mm | 152.5 CFM (4.27m³/min) | 1.200 in H2O (298.9 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 62.5dB(A) | 27.1 W | 7200 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-07W-B39-B50FAN AXIAL 92X38.4MM 48VDC WIRE |
3,138 |
|
规格书 |
3615RL | Box | Obsolete | 48VDC | Square - 92mm L x 92mm H | 38.40mm | 103.8 CFM (2.91m³/min) | 0.571 in H2O (142.2 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 52.5dB(A) | 10.1 W | 5000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-07W-B39-E50FAN AXIAL 92X38.4MM 48VDC WIRE |
1,433 |
|
规格书 |
3615RL | Box | Obsolete | 48VDC | Square - 92mm L x 92mm H | 38.40mm | 103.8 CFM (2.91m³/min) | 0.571 in H2O (142.2 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 52.5dB(A) | 10.1 W | 5000 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
|
|
3615RL-07W-B49-B50FAN AXIAL 92X38.4MM 48VDC WIRE |
4,753 |
|
规格书 |
3615RL | Box | Obsolete | 48VDC | Square - 92mm L x 92mm H | 38.40mm | 118.6 CFM (3.32m³/min) | 0.751 in H2O (187.0 Pa) | Ball | Tubeaxial | Speed Sensor (Tach) | 56.5dB(A) | 13.4 W | 5700 RPM | 3 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, UL, VDE | 0.507 lb (229.97 g) |
