购物车直流无刷风扇（BLDC）
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 额定电压 | 尺寸 / 尺寸 | 宽度 | 气流 | 静压 | 轴承类型 | 风扇类型 | 特性 | 噪音 | 功率（瓦特） | 转速（RPM） | 端接方式 | 防护等级 | 工作温度 | 认证机构 | 重量 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
3615KL-05W-B30-P00FAN AXIAL 92X38.4MM 24VDC WIRE |
4,949 |
|
规格书 |
3615KL | Bulk | Obsolete | 24VDC | Square - 92mm L x 92mm H | 38.40mm | 60.3 CFM (1.69m³/min) | 0.232 in H2O (57.8 Pa) | Ball | Tubeaxial | - | 40.5dB | 3.6 W | 3200 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.463 lb (210.01 g) |
|
|
3615KL-05W-B40-P00FAN AXIAL 92X38.4MM 24VDC WIRE |
3,975 |
|
规格书 |
3615KL | Bulk | Obsolete | 24VDC | Square - 92mm L x 92mm H | 38.40mm | 68.5 CFM (1.92m³/min) | 0.289 in H2O (72.0 Pa) | Ball | Tubeaxial | - | 44.0dB | 4.8 W | 3600 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.463 lb (210.01 g) |
|
4710KL-04W-B10-B00FAN AXIAL 119X25.5MM 12VDC WIRE |
4,028 |
|
规格书 |
4710KL | Bulk | Obsolete | 12VDC | Square - 119mm L x 119mm H | 25.50mm | 63.5 CFM (1.78m³/min) | 0.072 in H2O (17.9 Pa) | Ball | Tubeaxial | - | 27.0dB | 1.44 W | 1600 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.397 lb (180.08 g) |
|
|
4710KL-04W-B20-B00FAN AXIAL 119X25.5MM 12VDC WIRE |
3,217 |
|
规格书 |
4710KL | Bulk | Obsolete | 12VDC | Square - 119mm L x 119mm H | 25.50mm | 75.9 CFM (2.13m³/min) | 0.100 in H2O (24.9 Pa) | Ball | Tubeaxial | - | 31.0dB | 2.28 W | 1900 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.397 lb (180.08 g) |
|
|
4710KL-04W-B30-B00FAN AXIAL 119X25.5MM 12VDC WIRE |
3,002 |
|
规格书 |
4710KL | Bulk | Obsolete | 12VDC | Square - 119mm L x 119mm H | 25.50mm | 88.2 CFM (2.47m³/min) | 0.129 in H2O (32.1 Pa) | Ball | Tubeaxial | - | 35.0dB | 3.36 W | 2200 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.397 lb (180.08 g) |
|
|
4710KL-04W-B40-B00FAN AXIAL 119X25.5MM 12VDC WIRE |
4,358 |
|
规格书 |
4710KL | Bulk | Obsolete | 12VDC | Square - 119mm L x 119mm H | 25.50mm | 100.6 CFM (2.82m³/min) | 0.164 in H2O (40.9 Pa) | Ball | Tubeaxial | - | 38.5dB | 4.8 W | 2500 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.397 lb (180.08 g) |
|
|
4710KL-04W-B50-B00FAN AXIAL 119X25.5MM 12VDC WIRE |
3,786 |
|
规格书 |
4710KL | Bulk | Obsolete | 12VDC | Square - 119mm L x 119mm H | 25.50mm | 114.7 CFM (3.21m³/min) | 0.203 in H2O (50.6 Pa) | Ball | Tubeaxial | - | 41.5dB | 6.6 W | 2800 RPM | 2 Wire Leads | - | 14 ~ 140°F (-10 ~ 60°C) | CE, CSA, UL, VDE | 0.397 lb (180.08 g) |
|
|
4710KL-05W-B10-B00FAN AXIAL 119X25.5MM 24VDC WIRE |
4,854 |
|
规格书 |
4710KL | Bulk | Obsolete | 24VDC | Square - 119mm L x 119mm H | 25.50mm | 63.5 CFM (1.78m³/min) | 0.072 in H2O (17.9 Pa) | Ball | Tubeaxial | - | 27.0dB | 1.92 W | 1600 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.397 lb (180.08 g) |
|
|
4710KL-05W-B20-B00FAN AXIAL 119X25.5MM 24VDC WIRE |
3,913 |
|
规格书 |
4710KL | Bulk | Obsolete | 24VDC | Square - 119mm L x 119mm H | 25.50mm | 75.9 CFM (2.13m³/min) | 0.100 in H2O (24.9 Pa) | Ball | Tubeaxial | - | 31.0dB | 2.4 W | 1900 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.397 lb (180.08 g) |
|
|
4710KL-05W-B20-E00FAN AXIAL 119X25.5MM 24VDC WIRE |
4,003 |
|
规格书 |
4710KL | Bulk | Obsolete | 24VDC | Square - 119mm L x 119mm H | 25.50mm | 75.9 CFM (2.13m³/min) | 0.100 in H2O (24.9 Pa) | Ball | Tubeaxial | - | 31.0dB | 2.4 W | 1900 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.397 lb (180.08 g) |
|
|
4710KL-05W-B30-B00FAN AXIAL 119X25.5MM 24VDC WIRE |
3,276 |
|
规格书 |
4710KL | Bulk | Obsolete | 24VDC | Square - 119mm L x 119mm H | 25.50mm | 88.2 CFM (2.47m³/min) | 0.129 in H2O (32.1 Pa) | Ball | Tubeaxial | - | 35.0dB | 3.6 W | 2200 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.397 lb (180.08 g) |
|
|
4710KL-05W-B40-B00FAN AXIAL 119X25.5MM 24VDC WIRE |
3,371 |
|
规格书 |
4710KL | Bulk | Obsolete | 24VDC | Square - 119mm L x 119mm H | 25.50mm | 100.6 CFM (2.82m³/min) | 0.164 in H2O (40.9 Pa) | Ball | Tubeaxial | - | 38.5dB | 5.28 W | 2500 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.397 lb (180.08 g) |
|
|
4710KL-05W-B40-E00FAN AXIAL 119X25.5MM 24VDC WIRE |
2,028 |
|
规格书 |
4710KL | Bulk | Obsolete | 24VDC | Square - 119mm L x 119mm H | 25.50mm | 100.6 CFM (2.82m³/min) | 0.164 in H2O (40.9 Pa) | Ball | Tubeaxial | - | 38.5dB | 5.28 W | 2500 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.397 lb (180.08 g) |
|
|
4710KL-05W-B50-B00FAN AXIAL 119X25.5MM 24VDC WIRE |
3,029 |
|
规格书 |
4710KL | Bulk | Obsolete | 24VDC | Square - 119mm L x 119mm H | 25.50mm | 114.7 CFM (3.21m³/min) | 0.203 in H2O (50.6 Pa) | Ball | Tubeaxial | - | 41.5dB | 6.96 W | 2800 RPM | 2 Wire Leads | - | 14 ~ 140°F (-10 ~ 60°C) | CE, CSA, UL, VDE | 0.397 lb (180.08 g) |
|
4712KL-05W-B30-P00FAN AXIAL 119X32MM 24VDC WIRE |
4,059 |
|
规格书 |
4712KL | Bulk | Obsolete | 24VDC | Square - 119mm L x 119mm H | 32.00mm | 99.9 CFM (2.80m³/min) | 0.241 in H2O (60.0 Pa) | Ball | Tubeaxial | - | 44.0dB | 6.72 W | 2800 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.529 lb (239.95 g) |
|
|
4712KL-07W-B30-P00FAN AXIAL 119X32MM 48VDC WIRE |
2,208 |
|
规格书 |
4712KL | Bulk | Obsolete | 48VDC | Square - 119mm L x 119mm H | 32.00mm | 99.9 CFM (2.80m³/min) | 0.241 in H2O (60.0 Pa) | Ball | Tubeaxial | - | 44.0dB | 7.68 W | 2800 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.529 lb (239.95 g) |
|
4715SL-04W-B40-D00FAN AXIAL 119X38.4MM 12VDC WIRE |
1,866 |
|
规格书 |
4715SL | Bulk | Obsolete | 12VDC | Square - 119mm L x 119mm H | 38.40mm | 141.9 CFM (3.97m³/min) | 0.546 in H2O (136.0 Pa) | Ball | Tubeaxial | - | 53.5dB | 12 W | 3700 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.882 lb (400.07 g) |
|
|
4715SL-04W-B60-D00FAN AXIAL 119X38.4MM 12VDC WIRE |
1,706 |
|
规格书 |
4715SL | Bulk | Obsolete | 12VDC | Square - 119mm L x 119mm H | 38.40mm | 181.0 CFM (5.07m³/min) | 0.855 in H2O (213.0 Pa) | Ball | Tubeaxial | - | 59.5dB | 23 W | 4700 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.882 lb (400.07 g) |
|
|
4715SL-05W-B20-D00FAN AXIAL 119X38.4MM 24VDC WIRE |
1,931 |
|
规格书 |
4715SL | Bulk | Obsolete | 24VDC | Square - 119mm L x 119mm H | 38.40mm | 102.0 CFM (2.86m³/min) | 0.305 in H2O (75.9 Pa) | Ball | Tubeaxial | - | 45.0dB | 2 W | 2700 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.882 lb (400.07 g) |
|
|
4715SL-05W-B30-D00FAN AXIAL 119X38.4MM 24VDC WIRE |
3,537 |
|
规格书 |
4715SL | Bulk | Obsolete | 24VDC | Square - 119mm L x 119mm H | 38.40mm | 123.0 CFM (3.44m³/min) | 0.409 in H2O (102.0 Pa) | Ball | Tubeaxial | - | 49.5dB | 7 W | 3200 RPM | 2 Wire Leads | - | 14 ~ 158°F (-10 ~ 70°C) | CE, CSA, UL, VDE | 0.882 lb (400.07 g) |
