购物车DIP 开关
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 电路 | 位置数量 | 电流额定值（安培） | 电压额定值 | 执行器类型 | 执行器水平 | 触点材料 | 触点表面处理 | 板上高度 | 安装类型 | 端接样式 | 间距 | 可清洗 | 特性 | 工作温度 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RTE0400R74SW ROTARY DIP GRAY CODE 0.1A 30V |
1,213 |
|
规格书 |
RTE | Bulk | Obsolete | Gray Code | 4 | 100mA | 30VDC | Rotary for Tool | Flush, Recessed | Bronze | Gold | - | Through Hole, Reverse | PC Pin | 0.100" (2.54mm), Full | No | - | -25°C ~ 85°C |
|
|
RTE1002G54SWITCH ROTARY DIP 0.1A 30V |
1,563 |
|
规格书 |
RTE | Bulk | Obsolete | - | 10 | 100mA | 30VDC | Rotary with Shaft | Raised | Bronze | Gold | 0.322" (8.18mm) | Surface Mount | Gull Wing | 0.100" (2.54mm), Full | No | - | -25°C ~ 85°C |
|
|
RTE1002M14SWITCH ROTARY DIP BCD 0.1A 30V |
3,176 |
|
规格书 |
RTE | Bulk | Obsolete | BCD | 10 | 100mA | 30VDC | Rotary with Shaft | Raised | Bronze | Gold | 0.298" (7.57mm) | Through Hole | PC Pin | 0.100" (2.54mm), Full | No | - | -25°C ~ 85°C |
|
|
RTE1602M44SWITCH ROTARY DIP HEX 0.1A 30V |
2,190 |
|
规格书 |
RTE | Bulk | Obsolete | Hexadecimal | 16 | 100mA | 30VDC | Rotary with Shaft | Raised | Bronze | Gold | 0.298" (7.57mm) | Through Hole | PC Pin | 0.100" (2.54mm), Full | No | - | -25°C ~ 85°C |
|
DR3A-10R-BSWITCH ROTARY DIP BCD 0.025A 24V |
4,424 |
|
规格书 |
DR | Tube | Obsolete | BCD | 10 | 25mA | 24VDC | Rotary for Tool | Flush, Recessed | Copper | Gold | 0.390" (9.90mm) | Through Hole, Right Angle | PC Pin | 0.100" (2.54mm), Full | No | - | -25°C ~ 80°C |
|
|
DR3M-16R-BSWITCH ROTARY DIP HEX 0.025A 24V |
2,548 |
|
规格书 |
DR | Tube | Obsolete | Hexadecimal | 16 | 25mA | 24VDC | Rotary for Tool | Flush, Recessed | Copper | Gold | 0.177" (4.50mm) | Surface Mount | Gull Wing | 0.100" (2.54mm), Full | No | - | -25°C ~ 80°C |
|
|
DR4-10R-BSWITCH ROTARY DIP BCD 0.025A 24V |
2,470 |
|
规格书 |
DR | Tube | Obsolete | BCD | 10 | 25mA | 24VDC | Rotary for Tool | Flush, Recessed | Copper | Gold | 0.177" (4.50mm) | Through Hole | PC Pin | 0.100" (2.54mm), Full | No | - | -25°C ~ 80°C |
|
|
DR4A-16R-BSWITCH ROTARY DIP HEX 0.025A 24V |
3,706 |
|
规格书 |
DR | Tube | Obsolete | Hexadecimal | 16 | 25mA | 24VDC | Rotary for Tool | Flush, Recessed | Copper | Gold | 0.390" (9.90mm) | Through Hole, Right Angle | PC Pin | 0.100" (2.54mm), Full | No | - | -25°C ~ 80°C |
|
|
DR4AH-16R-BSWITCH ROTARY DIP HEX 0.025A 24V |
2,120 |
|
规格书 |
DR | Tube | Obsolete | Hexadecimal | 16 | 25mA | 24VDC | Rotary with Shaft | Raised | Copper | Gold | 0.390" (9.90mm) | Through Hole, Right Angle | PC Pin | 0.100" (2.54mm), Full | No | - | -25°C ~ 80°C |
|
|
DR75-AMP-10R-BSWITCH ROTARY DIP BCD 0.025A 24V |
2,481 |
|
规格书 |
DR75 | Tube | Obsolete | BCD | 10 | 25mA | 24VDC | Rotary for Tool | Flush, Recessed | Copper Alloy | Gold | 0.292" (7.41mm) | Surface Mount, Right Angle | Gull Wing | 0.050" (1.27mm), Half | No | - | -30°C ~ 80°C |
|
|
KAN1110RRSWITCH SLIDE DIP SPST 0.025A 24V |
1,049 |
|
规格书 |
KAN | Tape & Reel (TR) | Active | SPST | 10 | 25mA | 24VDC | Slide (Standard) | Flush, Recessed | Copper Alloy | Gold | 0.063" (1.60mm) | Surface Mount | Gull Wing | 0.050" (1.27mm), Half | Yes | Tape Seal | -40°C ~ 85°C |
|
|
KAP1102RSWITCH PIANO DIP SPST 0.025A 24V |
4,800 |
|
规格书 |
KAP | Tube | Active | SPST | 2 | 25mA | 24VDC | Piano | Flush, Recessed | Phosphor Bronze | Gold | 0.402" (10.20mm) | Through Hole, Right Angle | PC Pin | 0.100" (2.54mm), Full | No | - | -40°C ~ 85°C |
|
|
KAS2110ETSWITCH SLIDE DIP SPST 0.025A 24V |
3,853 |
|
规格书 |
KAS | Bulk | Active | SPST | 10 | 25mA | 24VDC | Slide (Standard) | Raised | Phosphor Bronze | Gold | 0.390" (9.90mm) | Through Hole, Right Angle | PC Pin | 0.100" (2.54mm), Full | Yes | Tape Seal | -40°C ~ 85°C |
|
|
SRJ-10SWITCH ROTARY DIP BCD 0.1A 5V |
3,868 |
|
规格书 |
SRJ | Tube | Active | BCD | 10 | 100mA | 5VDC | Rotary for Tool | Flush, Recessed | Glass Fabric Epoxy Resin | Gold | 0.256" (6.50mm) | Through Hole | PC Pin | 0.100" (2.54mm), Full | Yes | - | -10°C ~ 60°C |
|
|
SRJ-10HSWITCH ROTARY DIP BCD 0.1A 5V |
2,781 |
|
规格书 |
SRJ | Tube | Active | BCD | 10 | 100mA | 5VDC | Rotary with Shaft | Raised | Glass Fabric Epoxy Resin | Gold | 0.543" (13.80mm) | Through Hole | PC Pin | 0.100" (2.54mm), Full | Yes | - | -10°C ~ 60°C |
|
|
SRJ-16SWITCH ROTARY DIP HEX 0.1A 5V |
1,300 |
|
规格书 |
SRJ | Tube | Obsolete | Hexadecimal | 16 | 100mA | 5VDC | Rotary for Tool | Flush, Recessed | Glass Fabric Epoxy Resin | Gold | 0.256" (6.50mm) | Through Hole | PC Pin | 0.100" (2.54mm), Full | Yes | - | -10°C ~ 60°C |
|
|
SRJ-16CSW ROTARY DIP HEX COMP 0.1A 5V |
1,159 |
|
规格书 |
SRJ | Tube | Obsolete | Hexadecimal Complement | 16 | 100mA | 5VDC | Rotary for Tool | Flush, Recessed | Glass Fabric Epoxy Resin | Gold | 0.256" (6.50mm) | Through Hole | PC Pin | 0.100" (2.54mm), Full | Yes | - | -10°C ~ 60°C |
|
|
SRJ-8HSWITCH ROTARY DIP OCTAL 0.1A 5V |
4,897 |
|
规格书 |
SRJ | Tube | Active | Octal | 8 | 100mA | 5VDC | Rotary with Shaft | Raised | Glass Fabric Epoxy Resin | Gold | 0.543" (13.80mm) | Through Hole | PC Pin | 0.100" (2.54mm), Full | Yes | - | -10°C ~ 60°C |
|
|
SRK-10CSW ROTARY DIP BCD COMP 0.1A 5V |
4,007 |
|
规格书 |
SRK | Tube | Active | BCD Complement | 10 | 100mA | 5VDC | Rotary for Tool | Flush, Recessed | Glass Fabric Epoxy Resin | Gold | 0.256" (6.50mm) | Through Hole | PC Pin | 0.100" (2.54mm), Full | Yes | - | -10°C ~ 60°C |
|
|
SRM-10SWITCH ROTARY DIP BCD 0.1A 5V |
4,343 |
|
规格书 |
SRM | Tube | Obsolete | BCD | 10 | 100mA | 5VDC | Rotary for Tool | Flush, Recessed | Glass Fabric Epoxy Resin | Gold | 0.201" (5.10mm) | Surface Mount | Gull Wing | 0.100" (2.54mm), Full | Yes | - | -10°C ~ 60°C |
