购物车数字隔离器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 技术 | 类型 | 隔离电源 | 通道数 | 输入 - 侧 1/侧 2 | 通道类型 | 电压 - 隔离 | 共模瞬态抗扰度（最小值） | 数据速率 | 传播延迟 tpLH / tpHL（最大值） | 脉宽失真（最大值） | 上升/下降时间（典型值） | 电压 - 电源 | 等级 | 认证 | 工作温度 | 安装类型 | 供应商设备封装 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SI8421BD-D-ISDGTL ISO 5000VRMS 2CH GP 16SOIC |
3,538 |
|
规格书 |
- | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 2 | 1/1 | Unidirectional | 5000Vrms | 20kV/µs | 150Mbps | 11ns, 11ns | 3ns | 2ns, 2ns | 2.7V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
SI8055AA-B-IUDGTL ISO 1000VRMS 5CH GP 16QSOP |
3,719 |
|
规格书 |
- | 16-SSOP (0.154", 3.90mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 5 | 5/0 | Unidirectional | 1000Vrms | 35kV/µs | 10Mbps | 65ns, 65ns | 30ns | 2.5ns, 2.5ns | 3.15V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-QSOP |
|
|
SI8641ED-B-IS2DGTL ISO 5000VRMS 4CH GP 16SOIC |
3,450 |
|
规格书 |
Si864x | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 4 | 3/1 | Unidirectional | 5000Vrms | 50kV/µs | 150Mbps | 13ns, 13ns | 4.5ns | 4ns, 4ns | 2.5V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
|
SI8641ET-ISDGTL ISO 5000VRMS 4CH GP 16SOIC |
2,462 |
|
规格书 |
Si864x | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 4 | 3/1 | Unidirectional | 5000Vrms | 60kV/µs | 150Mbps | 13ns, 13ns | 4.5ns | 2.5ns, 2.5ns | 2.5V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
ADUM1100URZDGTL ISO 2500VRMS 1CH GP 8SOIC |
3,688 |
|
规格书 |
iCoupler® | 8-SOIC (0.154", 3.90mm Width) | Tube | Active | Magnetic Coupling | General Purpose | No | 1 | 1/0 | Unidirectional | 2500Vrms | 25kV/µs | 100Mbps | 18ns, 18ns | 2ns | 3ns, 3ns | 3V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 8-SOIC |
|
|
SI8642ET-ISDGTL ISO 5000VRMS 4CH GP 16SOIC |
4,315 |
|
规格书 |
Si864x | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 4 | 2/2 | Unidirectional | 5000Vrms | 60kV/µs | 150Mbps | 13ns, 13ns | 4.5ns | 2.5ns, 2.5ns | 2.5V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
SI8661AB-B-IS1DGTL ISO 2500VRMS 6CH GP 16SOIC |
1,269 |
|
规格书 |
- | 16-SOIC (0.154", 3.90mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 6 | 5/1 | Unidirectional | 2500Vrms | 35kV/µs | 1Mbps | 35ns, 35ns | 25ns | 2.5ns, 2.5ns | 2.5V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
|
SI8640ET-ISDGTL ISO 5000VRMS 4CH GP 16SOIC |
1,768 |
|
规格书 |
Si864x | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 4 | 4/0 | Unidirectional | 5000Vrms | 60kV/µs | 150Mbps | 13ns, 13ns | 4.5ns | 2.5ns, 2.5ns | 2.5V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
IL 610-2EDGTL ISO 2500VRMS 1CH GP 8DIP |
1,339 |
|
规格书 |
IsoLoop® | 8-DIP (0.300", 7.62mm) | Tube | Active | GMR (Giant Magnetoresistive) | General Purpose | No | 1 | 1/0 | Unidirectional | 2500Vrms | 15kV/µs | 100Mbps | 15ns, 15ns | 5ns | 2ns, 2ns | 3V ~ 5.5V | - | - | -40°C ~ 85°C | Through Hole | 8-PDIP |
|
|
SI8660AB-B-IS1DGTL ISO 2500VRMS 6CH GP 16SOIC |
1,372 |
|
规格书 |
- | 16-SOIC (0.154", 3.90mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 6 | 6/0 | Unidirectional | 2500Vrms | 35kV/µs | 1Mbps | 35ns, 35ns | 25ns | 2.5ns, 2.5ns | 2.5V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
|
SI8651BC-B-IS1DGTL ISO 3750VRMS 5CH GP 16SOIC |
4,949 |
|
规格书 |
- | 16-SOIC (0.154", 3.90mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 5 | 4/1 | Unidirectional | 3750Vrms | 35kV/µs | 150Mbps | 13ns, 13ns | 4.5ns | 2.5ns, 2.5ns | 2.5V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
ADUM2211SRIZDGTL ISO 5000VRMS 2CH GP 16SOIC |
4,891 |
|
规格书 |
iCoupler® | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Magnetic Coupling | General Purpose | No | 2 | 1/1 | Unidirectional | 5000Vrms | 25kV/µs | 1Mbps | 150ns, 150ns | 40ns | 10ns, 10ns | 3V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC-IC |
|
|
SI8663EB-B-IUDGTL ISO 2500VRMS 6CH GP 16QSOP |
1,622 |
|
规格书 |
- | 16-SSOP (0.154", 3.90mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 6 | 3/3 | Unidirectional | 2500Vrms | 50kV/µs | 150Mbps | 13ns, 13ns | 4.5ns | 4ns, 4ns | 2.5V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-QSOP |
|
LTC4310IMS-2#PBFDIGITAL ISOLATOR 2CH I2C 10MSOP |
4,085 |
|
规格书 |
- | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) | Tube | Active | Magnetic Coupling | I2C | No | 2 | 1/1 | Unidirectional | - | 20kV/µs | 400kHz | - | - | 1ns, 1ns | 3V ~ 5.5V | - | - | -40°C ~ 85°C | Surface Mount | 10-MSOP |
|
SI8380PF-IUDGTL ISO 2500VRMS 8CH GP 20QSOP |
3,533 |
|
规格书 |
- | 20-SSOP (0.154", 3.90mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 8 | 8/0 | Unidirectional | 2500Vrms | 200kV/µs | 250kbps | - | - | 3.9ns, 3.7ns | 2.25V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 20-QSOP |
|
SI86SS41BE-IS26.0 KVRMS SPI COMPATIBLE ISOLATO |
4,354 |
|
规格书 |
- | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | SPI | No | 4 | 3/1 | Unidirectional | 6000Vrms | 100kV/µs | 150Mbps | 14ns, 14ns | 2ns | 2.5ns, 2.5ns | 2.25V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
|
SI8661BD-B-IS2DGTL ISO 5000VRMS 6CH GP 16SOIC |
2,806 |
|
规格书 |
- | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Capacitive Coupling | General Purpose | No | 6 | 5/1 | Unidirectional | 5000Vrms | 50kV/µs | 150Mbps | 13ns, 13ns | 4.5ns | 4ns, 4ns | 2.5V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 16-SOIC |
|
|
ADUM3153ARSZDGT ISOL 3750VRMS 7CH SPI 20SSOP |
3,398 |
|
规格书 |
iCoupler®, SPIsolator™ | 20-SSOP (0.209", 5.30mm Width) | Tube | Active | Magnetic Coupling | SPI | No | 7 | 3/4 | Unidirectional | 3750Vrms | 25kV/µs | 2Mbps | 25ns, 25ns | 3ns | 2.5ns, 2.5ns | 3V ~ 5.5V | - | - | -40°C ~ 125°C | Surface Mount | 20-SSOP |
|
ADUM7643ARQZDGTL ISO 1000VRMS 6CH GP 20QSOP |
3,381 |
|
规格书 |
iCoupler® | 20-SSOP (0.154", 3.90mm Width) | Tube | Active | Magnetic Coupling | General Purpose | No | 6 | 3/3 | Unidirectional | 1000Vrms | 15kV/µs | 1Mbps | 75ns, 75ns | 25ns | 2ns, 2ns | 3V ~ 5.5V | - | - | -40°C ~ 105°C | Surface Mount | 20-QSOP |
|
ADUM3402CRWZDGTL ISO 2500VRMS 4CH GP 16SOIC |
2,318 |
|
规格书 |
iCoupler® | 16-SOIC (0.295", 7.50mm Width) | Tube | Active | Magnetic Coupling | General Purpose | No | 4 | 2/2 | Unidirectional | 2500Vrms | 25kV/µs | 90Mbps | 32ns, 32ns | 2ns | 2.5ns, 2.5ns | 3V ~ 5.5V | - | - | -40°C ~ 105°C | Surface Mount | 16-SOIC |
