购物车铝 - 聚合物电容器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 类型 | 电容 | 容差 | 额定电压 | ESR（等效串联电阻） | 寿命 @ 温度 | 工作温度 | 额定值 | 应用 | 特性 | 纹波电流 @ 低频 | 纹波电流 @ 高频 | 阻抗 | 引线间距 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） | 表面贴装焊盘尺寸 | 安装类型 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
94SVP337X0016F12CAP ALUM POLY 330UF 20% 16V SMD Vishay Sprague |
2,568 |
|
规格书 |
94SVP | Tape & Reel (TR) | Last Time Buy | Polymer | 330 µF | ±20% | 16 V | 17mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 4.58 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.500" (12.70mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount |
|
94SVPD186X0035F8CAP ALUM POLY 18UF 20% 35V SMD Vishay Sprague |
1,116 |
|
规格书 |
94SVPD | Tape & Reel (TR) | Last Time Buy | Polymer | 18 µF | ±20% | 35 V | 60mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | 27.5 mA @ 120 Hz | 550 mA @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.315" (8.00mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount |
|
94SVPD825X0035E7CAP ALUM POLY 8.2UF 20% 35V SMD Vishay Sprague |
4,879 |
|
规格书 |
94SVPD | Tape & Reel (TR) | Last Time Buy | Polymer | 8.2 µF | ±20% | 35 V | 70mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | 20 mA @ 120 Hz | 400 mA @ 100 kHz | - | - | 0.315" Dia (8.00mm) | 0.276" (7.00mm) | 0.327" L x 0.327" W (8.30mm x 8.30mm) | Surface Mount |
|
|
94SVP157X0020F12CAP ALUM POLY 150UF 20% 20V SMD Vishay Sprague |
4,047 |
|
规格书 |
94SVP | Tape & Reel (TR) | Last Time Buy | Polymer | 150 µF | ±20% | 20 V | 21mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 4.22 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.500" (12.70mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount |
|
|
94SVPD826X0025F12CAP ALUM POLY 82UF 20% 25V SMD Vishay Sprague |
2,444 |
|
规格书 |
94SVPD | Tape & Reel (TR) | Last Time Buy | Polymer | 82 µF | ±20% | 25 V | 28mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | 60.1 mA @ 120 Hz | 1.202 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.500" (12.70mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount |
|
|
94SVPD476X0035F12CAP ALUM POLY 47UF 20% 35V SMD Vishay Sprague |
2,262 |
|
规格书 |
94SVPD | Tape & Reel (TR) | Last Time Buy | Polymer | 47 µF | ±20% | 35 V | 30mOhm | 2000 Hrs @ 125°C | -55°C ~ 125°C | - | General Purpose | - | 57.5 mA @ 120 Hz | 1.15 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.500" (12.70mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount |
|
|
94SVP226X0025F8CAP ALUM POLY 22UF 20% 25V SMD Vishay Sprague |
2,978 |
|
规格书 |
94SVP | Tape & Reel (TR) | Obsolete | Polymer | 22 µF | ±20% | 25 V | 50mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2 A @ 100 kHz | - | - | 0.394" Dia (10.00mm) | 0.315" (8.00mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount |
|
|
94SVP336X0025E12CAP ALUM POLY 33UF 20% 25V SMD Vishay Sprague |
1,984 |
|
规格书 |
94SVP | Tape & Reel (TR) | Obsolete | Polymer | 33 µF | ±20% | 25 V | 30mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 2.98 A @ 100 kHz | - | - | 0.315" Dia (8.00mm) | 0.472" (12.00mm) | 0.327" L x 0.327" W (8.30mm x 8.30mm) | Surface Mount |
|
|
94SVP685X0025C6CAP ALUM POLY 6.8UF 20% 25V SMD Vishay Sprague |
3,986 |
|
规格书 |
94SVP | Bulk | Obsolete | Polymer | 6.8 µF | ±20% | 25 V | 80mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 1.2 A @ 100 kHz | - | - | 0.248" Dia (6.30mm) | 0.236" (6.00mm) | 0.260" L x 0.260" W (6.60mm x 6.60mm) | Surface Mount |
|
|
94SVP106X0025E7CAP ALUM POLY 10UF 20% 25V SMD Vishay Sprague |
4,976 |
|
规格书 |
94SVP | Bulk | Obsolete | Polymer | 10 µF | ±20% | 25 V | 60mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 1.5 A @ 100 kHz | - | - | 0.315" Dia (8.00mm) | 0.276" (7.00mm) | 0.327" L x 0.327" W (8.30mm x 8.30mm) | Surface Mount |
