购物车铝 - 聚合物电容器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 类型 | 电容 | 容差 | 额定电压 | ESR（等效串联电阻） | 寿命 @ 温度 | 工作温度 | 额定值 | 应用 | 特性 | 纹波电流 @ 低频 | 纹波电流 @ 高频 | 阻抗 | 引线间距 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） | 表面贴装焊盘尺寸 | 安装类型 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
94SVP107X0020E12CAP ALUM POLY 100UF 20% 20V SMD Vishay Sprague |
3,305 |
|
规格书 |
94SVP | Tape & Reel (TR) | Last Time Buy | Polymer | 100 µF | ±20% | 20 V | 25mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 3.26 A @ 100 kHz | - | - | 0.315" Dia (8.00mm) | 0.472" (12.00mm) | 0.327" L x 0.327" W (8.30mm x 8.30mm) | Surface Mount |
|
|
94SVP475X0010A5CAP ALUM POLY 4.7UF 20% 10V SMD Vishay Sprague |
1,964 |
|
规格书 |
94SVP | Tape & Reel (TR) | Last Time Buy | Polymer | 4.7 µF | ±20% | 10 V | 260mOhm | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 660 mA @ 100 kHz | - | - | 0.157" Dia (4.00mm) | 0.217" (5.50mm) | 0.169" L x 0.169" W (4.30mm x 4.30mm) | Surface Mount |
|
|
94SVP106X0010A5CAP ALUM POLY 10UF 20% 10V SMD Vishay Sprague |
2,855 |
|
规格书 |
94SVP | Tape & Reel (TR) | Last Time Buy | Polymer | 10 µF | ±20% | 10 V | 240mOhm | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 670 mA @ 100 kHz | - | - | 0.157" Dia (4.00mm) | 0.217" (5.50mm) | 0.169" L x 0.169" W (4.30mm x 4.30mm) | Surface Mount |
|
|
94SVP156X0010A5CAP ALUM POLY 15UF 20% 10V SMD Vishay Sprague |
3,812 |
|
规格书 |
94SVP | Tape & Reel (TR) | Last Time Buy | Polymer | 15 µF | ±20% | 10 V | 240mOhm | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 700 mA @ 100 kHz | - | - | 0.157" Dia (4.00mm) | 0.217" (5.50mm) | 0.169" L x 0.169" W (4.30mm x 4.30mm) | Surface Mount |
|
|
94SVP335X0016A5CAP ALUM POLY 3.3UF 20% 16V SMD Vishay Sprague |
4,040 |
|
规格书 |
94SVP | Tape & Reel (TR) | Last Time Buy | Polymer | 3.3 µF | ±20% | 16 V | 280mOhm | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 590 mA @ 100 kHz | - | - | 0.157" Dia (4.00mm) | 0.217" (5.50mm) | 0.169" L x 0.169" W (4.30mm x 4.30mm) | Surface Mount |
|
|
94SVP476X06R3B6CAP ALUM POLY 47UF 20% 6.3V SMD Vishay Sprague |
1,378 |
|
规格书 |
94SVP | Tape & Reel (TR) | Last Time Buy | Polymer | 47 µF | ±20% | 6.3 V | 90mOhm | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 1.06 A @ 100 kHz | - | - | 0.197" Dia (5.00mm) | 0.236" (6.00mm) | 0.209" L x 0.209" W (5.30mm x 5.30mm) | Surface Mount |
|
|
94SVP106X0020B6CAP ALUM POLY 10UF 20% 20V SMD Vishay Sprague |
3,858 |
|
规格书 |
94SVP | Tape & Reel (TR) | Last Time Buy | Polymer | 10 µF | ±20% | 20 V | 170mOhm | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 850 mA @ 100 kHz | - | - | 0.197" Dia (5.00mm) | 0.236" (6.00mm) | 0.209" L x 0.209" W (5.30mm x 5.30mm) | Surface Mount |
|
|
94SVP156X0016B6CAP ALUM POLY 15UF 20% 16V SMD Vishay Sprague |
4,351 |
|
规格书 |
94SVP | Tape & Reel (TR) | Last Time Buy | Polymer | 15 µF | ±20% | 16 V | 150mOhm | 1000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 920 mA @ 100 kHz | - | - | 0.197" Dia (5.00mm) | 0.236" (6.00mm) | 0.209" L x 0.209" W (5.30mm x 5.30mm) | Surface Mount |
|
|
94SVP566X0010C6CAP ALUM POLY 56UF 20% 10V SMD Vishay Sprague |
3,108 |
|
规格书 |
94SVP | Tape & Reel (TR) | Last Time Buy | Polymer | 56 µF | ±20% | 10 V | 55mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 1.51 A @ 100 kHz | - | - | 0.248" Dia (6.30mm) | 0.236" (6.00mm) | 0.260" L x 0.260" W (6.60mm x 6.60mm) | Surface Mount |
|
|
94SVP226X0020C6CAP ALUM POLY 22UF 20% 20V SMD Vishay Sprague |
2,394 |
|
规格书 |
94SVP | Tape & Reel (TR) | Last Time Buy | Polymer | 22 µF | ±20% | 20 V | 65mOhm | 2000 Hrs @ 105°C | -55°C ~ 105°C | - | General Purpose | - | - | 1.39 A @ 100 kHz | - | - | 0.248" Dia (6.30mm) | 0.236" (6.00mm) | 0.260" L x 0.260" W (6.60mm x 6.60mm) | Surface Mount |
