购物车交流直流桌面、墙式电源适配器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 使用区域 | 形式 | 输入类型 | 电压 - 输入 | 电压 - 输出 | 电流 - 输出（最大值） | 功率（瓦特） | 空载功耗 | 极化 | 应用 | 效率 | 工作温度 | 输出连接器 | 电线长度 | 输入连接器 | 特性 | 尺寸 / 尺寸 | 认证机构 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
EPS030100-P6RPAC/DC WALL MOUNT ADAPTER 3V 3W |
3,109 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 3V | 1A | 3 W | 500mW (Max) | Positive Center | ITE (Commercial) | Level IV | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS033100-P5PAC/DC WALL MNT ADAPTER 3.3V 3.3W |
3,175 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 3.3V | 1A | 3.3 W | 500mW (Max) | Positive Center | ITE (Commercial) | Level IV | 0°C ~ 40°C | Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS033100-P5RPAC/DC WALL MNT ADAPTER 3.3V 3.3W |
1,547 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 3.3V | 1A | 3.3 W | 500mW (Max) | Positive Center | ITE (Commercial) | Level IV | 0°C ~ 40°C | Barrel Plug R/A, 2.1mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS033100-P6PAC/DC WALL MNT ADAPTER 3.3V 3.3W |
1,213 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 3.3V | 1A | 3.3 W | 500mW (Max) | Positive Center | ITE (Commercial) | Level IV | 0°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS033100-P6RPAC/DC WALL MNT ADAPTER 3.3V 3.3W |
4,423 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 3.3V | 1A | 3.3 W | 500mW (Max) | Positive Center | ITE (Commercial) | Level IV | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS045100-P5RPAC/DC WALL MNT ADAPTER 4.5V 4.5W |
1,477 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 4.5V | 1A | 4.5 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.1mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS045100-P6PAC/DC WALL MNT ADAPTER 4.5V 4.5W |
1,116 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 4.5V | 1A | 4.5 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS045100-P6RPAC/DC WALL MNT ADAPTER 4.5V 4.5W |
4,150 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 4.5V | 1A | 4.5 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS050100-P6RPAC/DC WALL MOUNT ADAPTER 5V 5W |
4,401 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 5V | 1A | 5 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS060100-P6RPAC/DC WALL MOUNT ADAPTER 6V 6W |
4,555 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 6V | 1A | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS090066-P6RPAC/DC WALL MOUNT ADAPTER 9V 6W |
4,574 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 9V | 660mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS120050-P6PAC/DC WALL MOUNT ADAPTER 12V 6W |
4,207 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 12V | 500mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
EPS120050-P6RPAC/DC WALL MOUNT ADAPTER 12V 6W |
2,313 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 12V | 500mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS150040-P5RPAC/DC WALL MOUNT ADAPTER 15V 6W |
1,946 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 15V | 400mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.1mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS150040-P6PAC/DC WALL MOUNT ADAPTER 15V 6W |
1,789 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 15V | 400mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS150040-P6RPAC/DC WALL MOUNT ADAPTER 15V 6W |
2,109 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 15V | 400mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS180033-P5RPAC/DC WALL MOUNT ADAPTER 18V 6W |
4,180 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 18V | 330mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.1mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS240025-P5RPAC/DC WALL MOUNT ADAPTER 24V 6W |
1,570 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 24V | 250mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.1mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS240025-P6PAC/DC WALL MOUNT ADAPTER 24V 6W |
2,312 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 24V | 250mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
|
|
EPS240025-P6RPAC/DC WALL MOUNT ADAPTER 24V 6W |
1,850 |
|
规格书 |
EPS (6W) | Bulk | Obsolete | North America | Wall Mount (Class II) | Fixed Blade | 100 ~ 132 VAC | 24V | 250mA | 6 W | 300mW (Max) | Positive Center | ITE (Commercial) | Level V | 0°C ~ 40°C | Barrel Plug R/A, 2.5mm I.D. x 5.5mm O.D. x 12.0mm | 72" (1.83m) | NEMA 1-15P | - | 2.45" L x 1.06" W x 1.65" H (62.3mm x 26.8mm x 42.0mm) | cULus |
