| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输入 | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 电压 - 输出 4 | 电压 - 输出 5 | 电压 - 输出 6 | 电流 - 输出 1 | 电流 - 输出 2 | 电流 - 输出 3 | 电流 - 输出 4 | 电流 - 输出 5 | 电流 - 输出 6 | 功率（瓦特） | 应用 | 电压 - 隔离 | 工作温度 | 特性 | 安装类型 | 尺寸 / 尺寸 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LDA75F-12-YAC/DC CONVERTER 12V 76W |
3,514 |
|
规格书 |
LDA (75W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 12V | - | - | - | - | - | 6.3 A | - | - | - | - | - | 76W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) |
|
|
LDA75F-15-SNCYAC/DC CONVERTER 15V 75W |
2,785 |
|
规格书 |
LDA (75W) | Box | Obsolete | Enclosed | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 15V | - | - | - | - | - | 5 A | - | - | - | - | - | 75W | ITE (Commercial) | - | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 9.92" L x 2.56" W x 1.65" H (252.0mm x 65.0mm x 42.0mm) |
|
|
LDA75F-15-SNYAC/DC CONVERTER 15V 75W |
2,381 |
|
规格书 |
LDA (75W) | Box | Obsolete | Enclosed | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 15V | - | - | - | - | - | 5 A | - | - | - | - | - | 75W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 9.92" L x 2.56" W x 1.65" H (252.0mm x 65.0mm x 42.0mm) |
|
|
LDA75F-18AC/DC CONVERTER 18V 76W |
2,551 |
|
规格书 |
LDA (75W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 18V | - | - | - | - | - | 4.2 A | - | - | - | - | - | 76W | ITE (Commercial) | - | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) |
|
|
LDA75F-24-HAC/DC CONVERTER 24V 77W |
4,614 |
|
规格书 |
LDA (75W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 24V | - | - | - | - | - | 3.2 A | - | - | - | - | - | 77W | ITE (Commercial) | - | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) |
|
|
LDA75F-24-HRAC/DC CONVERTER 24V 77W |
2,417 |
|
规格书 |
LDA (75W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 24V | - | - | - | - | - | 3.2 A | - | - | - | - | - | 77W | ITE (Commercial) | - | -10°C ~ 60°C (With Derating) | Adjustable Output, Remote On/Off, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) |
|
|
LDA75F-24-LAC/DC CONVERTER 24V 77W |
1,244 |
|
规格书 |
LDA (75W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 24V | - | - | - | - | - | 3.2 A | - | - | - | - | - | 77W | ITE (Commercial) | - | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) |
|
|
LDA75F-24-RAC/DC CONVERTER 24V 77W |
1,969 |
|
规格书 |
LDA (75W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 24V | - | - | - | - | - | 3.2 A | - | - | - | - | - | 77W | ITE (Commercial) | - | -10°C ~ 60°C (With Derating) | Adjustable Output, Remote On/Off, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) |
|
|
LDA75F-24-SAC/DC CONVERTER 24V 77W |
1,113 |
|
规格书 |
LDA (75W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 24V | - | - | - | - | - | 3.2 A | - | - | - | - | - | 77W | ITE (Commercial) | - | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) |
|
|
LDA75F-24-SNAC/DC CONVERTER 24V 77W |
2,660 |
|
规格书 |
LDA (75W) | Box | Obsolete | Enclosed | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 24V | - | - | - | - | - | 3.2 A | - | - | - | - | - | 77W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 9.92" L x 2.56" W x 1.65" H (252.0mm x 65.0mm x 42.0mm) |
|
|
LDA75F-24-SNHAC/DC CONVERTER 24V 77W |
4,960 |
|
规格书 |
LDA (75W) | Box | Obsolete | Enclosed | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 24V | - | - | - | - | - | 3.2 A | - | - | - | - | - | 77W | ITE (Commercial) | - | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 9.92" L x 2.56" W x 1.65" H (252.0mm x 65.0mm x 42.0mm) |
|
|
LDA75F-24-SNRAC/DC CONVERTER 24V 77W |
3,821 |
|
规格书 |
LDA (75W) | Box | Obsolete | Enclosed | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 24V | - | - | - | - | - | 3.2 A | - | - | - | - | - | 77W | ITE (Commercial) | - | -10°C ~ 60°C (With Derating) | Adjustable Output, Remote On/Off, Universal Input | Chassis Mount | 9.92" L x 2.56" W x 1.65" H (252.0mm x 65.0mm x 42.0mm) |
|
|
LDA75F-24-SNYAC/DC CONVERTER 24V 77W |
3,224 |
|
规格书 |
LDA (75W) | Box | Obsolete | Enclosed | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 24V | - | - | - | - | - | 3.2 A | - | - | - | - | - | 77W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 9.92" L x 2.56" W x 1.65" H (252.0mm x 65.0mm x 42.0mm) |
|
|
LDA75F-24-YAC/DC CONVERTER 24V 77W |
3,658 |
|
规格书 |
LDA (75W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 24V | - | - | - | - | - | 3.2 A | - | - | - | - | - | 77W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) |
|
|
LDA75F-3AC/DC CONVERTER 3V 45W |
3,617 |
|
规格书 |
LDA (75W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 3V | - | - | - | - | - | 15 A | - | - | - | - | - | 45W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) |
|
|
LDA75F-30-YAC/DC CONVERTER 30V 75W |
2,112 |
|
规格书 |
LDA (75W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 30V | - | - | - | - | - | 2.5 A | - | - | - | - | - | 75W | ITE (Commercial) | - | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) |
|
|
LDA75F-5-RYAC/DC CONVERTER 5V 75W |
2,709 |
|
规格书 |
LDA (75W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 5V | - | - | - | - | - | 15 A | - | - | - | - | - | 75W | ITE (Commercial) | - | -10°C ~ 60°C (With Derating) | Adjustable Output, Remote On/Off, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.26" H (222.0mm x 55.0mm x 32.0mm) |
|
|
LDA75F-5-SNAC/DC CONVERTER 5V 75W |
2,210 |
|
规格书 |
LDA (75W) | Box | Obsolete | Enclosed | 1 | 85 ~ 264 VAC, 110 ~ 370 VDC | 5V | - | - | - | - | - | 15 A | - | - | - | - | - | 75W | ITE (Commercial) | 3 kV | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 9.92" L x 2.56" W x 1.65" H (252.0mm x 65.0mm x 42.0mm) |
|
LDC15F-1-CAC/DC CONVERTER 5V +/-12V 10W |
1,924 |
|
规格书 |
LDC (15W) | Box | Obsolete | Open Frame, Conformal Coated | 3 | 85 ~ 264 VAC, 110 ~ 370 VDC | 5V | 12V | -12V | - | - | - | 2 A | 300 mA | 200 mA | - | - | - | 10W | ITE (Commercial) | - | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 1.97" L x 1.02" W x 5.00" H (50.0mm x 25.9mm x 127.0mm) |
|
|
LDC15F-1-GAC/DC CONVERTER 5V +/-12V 10W |
1,991 |
|
规格书 |
LDC (15W) | Box | Obsolete | Open Frame | 3 | 85 ~ 264 VAC, 110 ~ 370 VDC | 5V | 12V | -12V | - | - | - | 2 A | 300 mA | 200 mA | - | - | - | 10W | ITE (Commercial) | - | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 1.97" L x 1.02" W x 5.00" H (50.0mm x 25.9mm x 127.0mm) |
