购物车钽 - 聚合物电容器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 电容 | 容差 | 额定电压 | 类型 | ESR（等效串联电阻） | 工作温度 | 寿命 @ 温度 | 安装类型 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） | 引线间距 | 制造商尺寸代码 | 额定值 | 特性 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
.jpg)
|
TCQD336M016R0070CAP TANT POLY 33UF 16V 2917 KYOCERA AVX |
7,507 |
|
- |
TCQ | 2917 (7343 Metric) | Tape & Reel (TR) | Discontinued at Digi-Key | 33 µF | ±20% | 16 V | Molded | 70mOhm @ 100kHz | -55°C ~ 125°C | 1000 Hrs @ 125°C | Surface Mount | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.122" (3.10mm) | - | D | AEC-Q200 | Automotive |
|
TCME108M002R0006CAP TANT POLY 1000UF 2.5V 2917 KYOCERA AVX |
6,837 |
|
- |
TCM | 2917 (7343 Metric) | Tape & Reel (TR) | Discontinued at Digi-Key | 1000 µF | ±20% | 2.5 V | Molded | 6mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.169" (4.30mm) | - | E | - | General Purpose |
|
|
TCME108M002R0010CAP TANT POLY 1000UF 2.5V 2917 KYOCERA AVX |
9,664 |
|
- |
TCM | 2917 (7343 Metric) | Tape & Reel (TR) | Discontinued at Digi-Key | 1000 µF | ±20% | 2.5 V | Molded | 10mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.169" (4.30mm) | - | E | - | General Purpose |
-TCN-O-Chip-Caps.jpg)
|
TCNO106M010R0500CAP TANT POLY 10UF 10V 1206 KYOCERA AVX |
6,264 |
|
- |
TCN | 1206 (3216 Metric) | Cut Tape (CT) | Discontinued at Digi-Key | 10 µF | ±20% | 10 V | Molded | 500mOhm @ 100kHz | -55°C ~ 105°C | 2000 Hrs @ 105°C | Surface Mount | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.024" (0.60mm) | - | O | - | General Purpose |
|
TCBD226M020CRSZ0700CAP TANT POLY 22UF 20V 2917 KYOCERA AVX |
4,646 |
|
- |
TCB | 2917 (7343 Metric) | Tape & Reel (TR) | Discontinued at Digi-Key | 22 µF | ±20% | 20 V | Molded | 70mOhm @ 100kHz | -55°C ~ 125°C | 2000 Hrs @ 125°C | Surface Mount | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.122" (3.10mm) | - | D | COTS | High Reliability |
|
|
TCBD106M035CRSZ0700CAP TANT POLY 10UF 35V 2917 KYOCERA AVX |
2,438 |
|
- |
TCB | 2917 (7343 Metric) | Tape & Reel (TR) | Discontinued at Digi-Key | 10 µF | ±20% | 35 V | Molded | 70mOhm @ 100kHz | -55°C ~ 125°C | 2000 Hrs @ 125°C | Surface Mount | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.122" (3.10mm) | - | D | COTS | High Reliability |
|
|
TCBD686M010CRSZ0723CAP TANT POLY 68UF 10V 2917 KYOCERA AVX |
4,254 |
|
- |
TCB | 2917 (7343 Metric) | Tape & Reel (TR) | Active | 68 µF | ±20% | 10 V | Molded | 70mOhm @ 100kHz | -55°C ~ 125°C | 2000 Hrs @ 125°C | Surface Mount | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.122" (3.10mm) | - | D | COTS | General Purpose |
|
|
TCBD227M004CRSZ0724CAP TANT POLY 220UF 4V 2917 KYOCERA AVX |
3,954 |
|
- |
TCB | 2917 (7343 Metric) | Tape & Reel (TR) | Active | 220 µF | ±20% | 4 V | Molded | 40mOhm @ 100kHz | -55°C ~ 125°C | 2000 Hrs @ 125°C | Surface Mount | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.122" (3.10mm) | - | D | COTS | General Purpose |
|
|
TCBD476M016CRSZ0H24CAP TANT POLY 47UF 16V 2917 KYOCERA AVX |
5,009 |
|
- |
TCB | 2917 (7343 Metric) | Tape & Reel (TR) | Active | 47 µF | ±20% | 16 V | Molded | 65mOhm @ 100kHz | -55°C ~ 125°C | 2000 Hrs @ 125°C | Surface Mount | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.122" (3.10mm) | - | D | COTS | General Purpose |
|
|
TCBD157M006CRSZ0H24CAP TANT POLY 150UF 6.3V 2917 KYOCERA AVX |
3,186 |
|
- |
TCB | 2917 (7343 Metric) | Tape & Reel (TR) | Active | 150 µF | ±20% | 6.3 V | Molded | 40mOhm @ 100kHz | -55°C ~ 125°C | 2000 Hrs @ 125°C | Surface Mount | 0.287" L x 0.169" W (7.30mm x 4.30mm) | 0.122" (3.10mm) | - | D | COTS | General Purpose |
