购物车直流直流转换器（DC DC Converters）
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输入（最小） | 电压 - 输入（最大） | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 电压 - 输出 4 | 电流 - 输出（最大值） | 功率（瓦特） | 电压 - 隔离 | 应用 | 特性 | 工作温度 | 效率 | 等级 | 认证 | 安装类型 | 供应商设备封装 | 控制特性 | 认证机构 | 标准编号 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AM6O-2412SNZDC DC CONVERTER 12V 6W |
4,075 |
|
规格书 |
AM6O-NZ (6W) | - | Bulk | Active | Isolated Module | 1 | 18V | 36V | 12V | - | - | - | 500mA | 6 W | 500 V | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 85°C | 85% | - | - | Through Hole | - | - | - | - |
|
|
AM6O-2405SNZDC DC CONVERTER 5V 6W |
1,846 |
|
规格书 |
AM6O-NZ (6W) | - | Bulk | Active | Isolated Module | 1 | 18V | 36V | 5V | - | - | - | 1.2A | 6 W | 500 V | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 85°C | 83% | - | - | Through Hole | - | - | - | - |
|
AM60EW-4812DZDC DC CONVERTER +/-12V 60W |
4,006 |
|
规格书 |
AM60EW-Z (60W) | - | Tube | Active | Isolated Module | 2 | 18V | 75V | -12 ~ 12V | -12V | - | - | 2.5A, 2.5A | 60 W | 1.6 kV | ITE (Commercial) | Adjustable Output, Remote On/Off | -40°C ~ 75°C | 91% | - | - | Through Hole | - | - | CE, cURus, UL | - |
|
AM10G-2409NZDC DC CONVERTER 9V 10W |
1,491 |
|
规格书 |
AM10G-NZ (10W) | 8-SIP Module | Tube | Active | Isolated Module | 1 | 18V | 36V | 9V | - | - | - | 1.11A | 10 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 86% | - | - | Through Hole | - | - | - | - |
|
AM20E-2409D-NZDC DC CONVERTER +/-9V 20W |
2,437 |
|
规格书 |
AM20E-NZ (20W) | - | Tube | Active | Isolated Module | 2 | 18V | 36V | -9 ~ 9V | -9V | - | - | 1.11A, 1.11A | 20 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 88% | - | - | Through Hole | - | - | CE | - |
|
|
AM50E-4824S-NZ-KDC DC CONVERTER 24V 50W |
2,716 |
|
规格书 |
AM50E-NZ (50W) | 6-DIP Module | Tube | Active | Isolated Module | 1 | 36V | 75V | 24V | - | - | - | 2.083A | 50 W | 1.5 kV | ITE (Commercial) | Heat Sink, Remote On/Off | -40°C ~ 65°C (With Derating) | 93% | - | - | Through Hole | - | - | cURus | - |
|
AM1LS-0505D-NZDC DC CONVERTER +/-5V 1W |
1,266 |
|
规格书 |
AM1LS-NZ (1W) | SMD | Tube | Active | Isolated Module | 2 | 4.5V | 5.5V | -5 ~ 5V | -5V | - | - | 100mA, 100mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 82% | - | - | Surface Mount | - | - | cULus, cURus | - |
|
AM1LS-0505DH30VZDC DC CONVERTER +/-5V 1W |
1,182 |
|
规格书 |
AM1LS-VZ (1W) | SMD | Obsolete | Isolated Module | 2 | 4.5V | 5.5V | -5 ~ 5V | -5V | - | - | 100mA, 100mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C | 82% | - | - | Surface Mount | - | - | - | - | |
|
AM1L-0305S-NZDC DC CONVERTER 5V 1W |
1,115 |
|
规格书 |
AM1L-NZ (1W) | SMD | Tube | Active | Isolated Module | 1 | 3V | 3.6V | 5V | - | - | - | 200mA | 1 W | 1 kV | ITE (Commercial) | - | -40°C ~ 85°C | 71% | - | - | Surface Mount | - | - | CE, cULus, cURus | - |
|
AM10CW-4815D-NZDC DC CONVERTER +/-15V 10W |
1,029 |
|
规格书 |
AM10CW-NZ (10W) | - | Obsolete | Isolated Module | 2 | 18V | 75V | -15 ~ 15V | -15V | - | - | 330mA, 330mA | 10 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 87% | - | - | Through Hole | - | - | CE, cURus, UL | - | |
|
AM6T-1205D-NZDC DC CONVERTER +/-5V 6W |
4,798 |
|
规格书 |
AM6T-NZ (6W) | 24-DIP Module | Tube | Active | Isolated Module | 2 | 9V | 18V | -5 ~ 5V | -5V | - | - | 600mA, 600mA | 6 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C | 80% | - | - | Through Hole | - | - | CE | - |
|
AM200QB-4824SH22-NZDC DC CONVERTER 24V 202W |
3,907 |
|
规格书 |
AM200QB-NZ (200W) | Quarter Brick | Bulk | Active | Isolated Module | 1 | 18V | 75V | 24V | - | - | - | 8.4A | 200 W | 2.25 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 91% | - | - | Through Hole | Quarter Brick | - | - | - |
|
|
AM10CW-4812S-NZDC DC CONVERTER 12V 10W |
4,140 |
|
规格书 |
AM10CW-NZ (10W) | - | Obsolete | Isolated Module | 1 | 18V | 75V | 12V | - | - | - | 830mA | 10 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 87% | - | - | Through Hole | - | - | CE, cURus, UL | - | |
|
AM1LS-0509SJZDC DC CONVERTER 9V 999MW |
3,981 |
|
规格书 |
AM1LS-NZ (1W) | SMD | Obsolete | Isolated Module | 1 | 4.5V | 5.5V | 9V | - | - | - | 111mA | 1 mW | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 80% | - | - | Surface Mount | - | - | cULus, cURus | - | |
|
|
AM1LS-0505SJZTRDC DC CONVERTER 5V 1W |
2,486 |
|
规格书 |
AM1LS-NZ (1W) | SMD | Obsolete | Isolated Module | 1 | 4.5V | 5.5V | 5V | - | - | - | 200mA | 1 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 105°C | 82% | - | - | Surface Mount | - | - | cULus, cURus | - | |
|
AM1DS-1215SH30-NZDC DC CONVERTER 15V 1W |
3,487 |
|
规格书 |
AM1DS-NZ (1W) | 7-SIP Module | Tube | Active | Isolated Module | 1 | 10.8V | 13.2V | 15V | - | - | - | 67mA | 1 W | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C | 81% | - | - | Through Hole | - | - | cULus, cURus | - |
|
|
AM10CW-4824S-NZDC DC CONVERTER 24V 9.8W |
4,977 |
|
规格书 |
AM10CW-NZ (10W) | - | Obsolete | Isolated Module | 1 | 18V | 75V | 24V | - | - | - | 410mA | 10 W | 1.5 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 88% | - | - | Through Hole | - | - | CE, cURus, UL | - | |
|
|
AM6T-1205S-NZDC DC CONVERTER 5V 6W |
1,425 |
|
规格书 |
AM6T-NZ (6W) | 24-DIP Module | Obsolete | Isolated Module | 1 | 9V | 18V | 5V | - | - | - | 1.2A | 6 W | 1.5 kV | ITE (Commercial) | - | -40°C ~ 85°C | 80% | - | - | Through Hole | - | - | CE | - | |
|
AM1LS-0509SH30VZDC DC CONVERTER 9V 999MW |
3,193 |
|
规格书 |
AM1LS-VZ (1W) | SMD | Tube | Active | Isolated Module | 1 | 4.5V | 5.5V | 9V | - | - | - | 111mA | 1 mW | 3 kV | ITE (Commercial) | - | -40°C ~ 105°C | 83% | - | - | Surface Mount | - | - | - | - |
|
AM15T-1215DZDC DC CONVERTER +/-15V 15W |
2,693 |
|
规格书 |
AM15T-Z (15W) | 24-DIP Module | Tube | Active | Isolated Module | 2 | 9V | 18V | -15 ~ 15V | -15V | - | - | 500mA, 500mA | 15 W | 1.6 kV | ITE (Commercial) | Remote On/Off | -40°C ~ 85°C | 90% | - | - | Through Hole | - | - | CE | - |
