购物车多导体电缆
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 电缆类型 | 导体数量 | 线规 | 导体股数 | 导体材料 | 护套（绝缘）材料 | 护套（绝缘）直径 | 屏蔽类型 | 长度 | 护套颜色 | 额定值 | 特性 | 电压 | 工作温度 | 用途 | 护套（绝缘）厚度 | 导体绝缘 | 尺寸 / 尺寸 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
8489ZH 010500CABLE 4COND 18AWG BLACK 500' |
2,748 |
|
规格书 |
- | Spool | Active | Multi-Conductor | 4 | 18 AWG | 19/30 | Copper, Tinned | Low Smoke Zero Halogen (LSZH) | 0.243" (6.17mm) | - | 500.0' (152.4m) | Black | UL Style 21305 | - | 300 V | -20°C ~ 60°C | - | 0.0320" (0.813mm) | Polypropylene (PP) | - |
|
9507 060U500MULTI-PAIR 14COND 24AWG 500' |
3,834 |
|
规格书 |
Classics | Spool | Active | Multi-Pair | 14 (7 Pair Twisted) | 24 AWG | 7/32 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.294" (7.47mm) | Foil | 500.0' (152.4m) | Chrome | UL Style 2464 | Drain Wire | 300 V | -30°C ~ 80°C | Computer | 0.0320" (0.813mm) | Poly-Vinyl Chloride (PVC) | - |
|
|
8777ZH E4X1000MULTI-PAIR 6CON 22AWG GRAY 1000' |
1,924 |
|
- |
- | Spool | Active | Multi-Pair | 6 (3 Pair Twisted) | 22 AWG | 7/30 | Copper, Tinned | Low Smoke Zero Halogen (LSZH) | 0.273" (6.93mm) | Foil | 1000.0' (304.8m) | Gray | - | Drain Wire | 300 V | -20°C ~ 80°C | - | 0.0340" (0.864mm) | Polypropylene (PP) | - |
|
|
83756 002500CABLE 6COND 14AWG RED SHLD 500' |
1,120 |
|
规格书 |
- | Spool | Active | Multi-Conductor | 6 | 14 AWG | 7/22 | Copper, Tinned | Fluorinated Ethylene-Propylene (FEP), Plenum | 0.376" (9.55mm) | Foil, Braid | 500.0' (152.4m) | Red | UL Style CMP | - | 300 V | -70°C ~ 200°C | Alarm, Safety | 0.0170" (0.432mm) | Fluorinated Ethylene-Propylene (FEP) | - |
|
|
8761ZH 060500CABLE 2CON 22AWG CHROM SHLD 500' |
2,830 |
|
规格书 |
- | Spool | Active | Multi-Conductor | 2 (1 Pair Twisted) | 22 AWG | 7/30 | Copper, Tinned | Low Smoke Zero Halogen (LSZH) | 0.175" (4.45mm) | Foil | 500.0' (152.4m) | Chrome | UL Style 21305 | Drain Wire | 300 V | -20°C ~ 75°C | - | 0.0250" (0.635mm) | Polyethylene (PE) | - |
|
|
9154ZH 010500CABLE 2COND 20AWG BLK SHLD 500' |
1,790 |
|
规格书 |
- | Spool | Active | Multi-Conductor | 2 (1 Pair Twisted) | 20 AWG | 7/28 | Copper, Tinned | Low Smoke Zero Halogen (LSZH) | - | Foil | 500.0' (152.4m) | Black | UL Style 21307 | Drain Wire | 300 V | -20°C ~ 75°C | - | 0.0310" (0.787mm) | Polypropylene (PP) | - |
|
|
9842NH 0601000MULTI-PAIR 4COND 24AWG 1000' |
3,458 |
|
规格书 |
- | Spool | Active | Multi-Pair | 4 (2 Pair Twisted) | 24 AWG | 7/32 | Copper, Tinned | Low Smoke Zero Halogen (LSZH) | 0.323" (8.20mm) | Foil, Braid | 1000.0' (304.8m) | Chrome | UL Style 2919 | Drain Wire | 300 V | -20°C ~ 80°C | Computer | 0.0350" (0.889mm) | Polyethylene (PE) | - |
|
|
9842 06010000MULTI-PAIR 4COND 24AWG 10000' |
2,921 |
|
规格书 |
- | Spool | Active | Multi-Pair | 4 (2 Pair Twisted) | 24 AWG | 7/32 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.340" (8.64mm) | Foil, Braid | 10000' (3048.0m) | Chrome | UL Style 2919 | Drain Wire | 300 V | -30°C ~ 80°C | Computer | 0.0350" (0.889mm) | Polyethylene (PE) | - |
|
|
9855 01010000MULTI-PAIR 4COND 22AWG 10000' |
3,233 |
|
规格书 |
- | Spool | Active | Multi-Pair | 4 (2 Pair Twisted) | 22 AWG | Solid | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.270" (6.86mm) | Foil, Braid | 10000' (3048.0m) | Black | UL Style 2582 | Drain Wire | 300 V | -20°C ~ 60°C | Computer | 0.0330" (0.838mm) | Polyethylene (PE) | - |
|
|
9934 0605000CABLE 9COND 24AWG CHRM SHD 5000' |
2,401 |
|
规格书 |
- | Spool | Active | Multi-Conductor | 9 | 24 AWG | 7/32 | Copper, Tinned | Poly-Vinyl Chloride (PVC) | 0.300" (7.62mm) | Foil, Braid | 5000' (1524.0m) | Chrome | UL Style 2919 | Drain Wire | - | -30°C ~ 80°C | Computer | 0.0350" (0.889mm) | Foam Polyethylene (FPE) | - |
|
|
1326A D15500MULTI-PAIR 6COND 22AWG BLUE 500' |
1,308 |
|
规格书 |
- | Spool | Active | Multi-Pair | 6 (3 Pair) | 22 AWG | 7/30 | Copper, Tinned | Poly-Vinyl Chloride (PVC), Plenum | 0.190" (4.83mm) | Foil | 500.0' (152.4m) | Blue | - | Drain Wire | 300 V | 0°C ~ 75°C | Security, Sound | - | Poly-Vinyl Chloride (PVC) | - |
|
|
1326A 009500MULTI-PAIR 6COND 22AWG WHT 500' |
2,335 |
|
规格书 |
- | Spool | Active | Multi-Pair | 6 (3 Pair) | 22 AWG | 7/30 | Copper, Tinned | Poly-Vinyl Chloride (PVC), Plenum | 0.190" (4.83mm) | Foil | 500.0' (152.4m) | White | - | Drain Wire | 300 V | 0°C ~ 75°C | Security, Sound | - | Poly-Vinyl Chloride (PVC) | - |
|
|
5320UL D15C500CABLE 2COND 18AWG BLUE 500' |
2,752 |
|
规格书 |
- | Spool | Active | Multi-Conductor | 2 | 18 AWG | Solid | Copper, Bare | Poly-Vinyl Chloride (PVC), Riser | 0.143" (3.63mm) | - | 500.0' (152.4m) | Blue | UL Style FPLR | Rip Cord | 300 V | -20°C ~ 75°C | Alarm, Safety | 0.0170" (0.432mm) | Polypropylene (PP) | - |
|
5502UE 008C500CABLE 4COND 22AWG GRAY 500' |
1,755 |
|
规格书 |
- | Spool | Active | Multi-Conductor | 4 | 22 AWG | 7/30 | Copper, Bare | Poly-Vinyl Chloride (PVC), Riser | 0.141" (3.58mm) | - | 500.0' (152.4m) | Gray | UL Style CMR | Rip Cord | 300 V | -20°C ~ 75°C | Security, Sound | 0.0170" (0.432mm) | Polypropylene (PP) | - |
|
|
5582UE 009C500CABLE 4COND 22AWG WHITE 500' |
3,520 |
|
规格书 |
- | Spool | Active | Multi-Conductor | 4 | 22 AWG | Solid | Copper, Bare | Poly-Vinyl Chloride (PVC), Riser | 0.130" (3.30mm) | - | 500.0' (152.4m) | White | UL Style CMR | Rip Cord | 300 V | -20°C ~ 75°C | Security, Sound | 0.0170" (0.432mm) | Polypropylene (PP) | - |
|
|
6320UL 009C500CABLE 2COND 18AWG WHITE 500' |
3,336 |
|
规格书 |
- | Spool | Active | Multi-Conductor | 2 | 18 AWG | Solid | Copper, Bare | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 0.144" (3.66mm) | - | 500.0' (152.4m) | White | UL Style FPLP | Rip Cord | 300 V | 0°C ~ 75°C | Alarm, Safety | 0.0150" (0.381mm) | Low Smoke Poly-Vinyl Chloride (LSPVC) | - |
|
6502UE 877C500CABLE 4COND 22AWG NATURAL 500' |
1,121 |
|
规格书 |
- | Spool | Active | Multi-Conductor | 4 | 22 AWG | 7/30 | Copper, Bare | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 0.139" (3.53mm) | - | 500.0' (152.4m) | Natural | UL Style CMP | Rip Cord | 300 V | 0°C ~ 75°C | Security, Sound | 0.0150" (0.381mm) | Low Smoke Poly-Vinyl Chloride (LSPVC) | - |
|
|
6524UE 877C500CABLE 6COND 22AWG NATURAL 500' |
2,596 |
|
规格书 |
- | Spool | Active | Multi-Conductor | 6 | 22 AWG | Solid | Copper, Bare | Low Smoke Poly-Vinyl Chloride (LSPVC), Plenum | 0.162" (4.11mm) | - | 500.0' (152.4m) | Natural | UL Style CMP | Rip Cord | 300 V | 0°C ~ 75°C | Security, Sound | 0.0150" (0.381mm) | Low Smoke Poly-Vinyl Chloride (LSPVC) | - |
|
|
1326A D151000MULTI-PAIR 6COND 22AWG BLU 1000' |
4,617 |
|
规格书 |
- | Spool | Active | Multi-Pair | 6 (3 Pair) | 22 AWG | 7/30 | Copper, Tinned | Poly-Vinyl Chloride (PVC), Plenum | 0.190" (4.83mm) | Foil | 1000.0' (304.8m) | Blue | - | Drain Wire | 300 V | 0°C ~ 75°C | Security, Sound | - | Poly-Vinyl Chloride (PVC) | - |
|
|
5500UG U4FC1000CABLE 2COND 22AWG BEIGE 1000' |
2,300 |
|
规格书 |
- | Spool | Active | Multi-Conductor | 2 | 22 AWG | 7/30 | Copper, Bare | Poly-Vinyl Chloride (PVC) | 0.114" (2.89mm) | - | 1000.0' (304.8m) | Beige | - | - | 300 V | -20°C ~ 75°C | Security, Sound | 0.0150" (0.381mm) | Polypropylene (PP) | - |
