购物车工业用 DIN 导轨电源
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 输入类型 | 输出数量 | 交流电压 - 输入 | 直流电压 - 输入（最小值） | 直流电压 - 输入（最大值） | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 电压 - 输出 4 | 电压 - 输出 5 | 电压 - 输出 6 | 电流 - 输出（最大值） | 功率（瓦特） | 电压 - 隔离 | 应用 | 效率 | 工作温度 | 特性 | 认证机构 | 标准编号 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SPDE242402RSWITCHING POWER SUPPLY, AC/DC, 2 |
1,765 |
|
- |
SPDE (240W) | Bulk | Active | AC or DC | 1 | 180 ~ 550 VAC (2 Phase) | 254V | 780V | 24V | - | - | - | - | - | 10A | 240W | 4 kV | Household Appliances, ITE (Commercial), Laboratory | 91% | -40°C ~ 70°C (With Derating) | Adjustable Output, IP20, Remote On/Off, Universal Input | CE, cULus, UKCA | 60335-1; 61010-1; 62368-1 |
|
|
15193.2AC/DC DIN RAIL SUPPLY |
2,066 |
|
- |
* | Box | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
PSDR0400AC/DC DIN RAIL SUPPLY 24V 96W |
4,033 |
|
规格书 |
PSDR | Box | Obsolete | AC | 1 | 85 ~ 264 VAC | - | - | 24V | - | - | - | - | - | 4A | 96W | 3 kV | ITE (Commercial) | 80% | -25°C ~ 60°C | Adjustable Output, Universal Input | CE, cULus, cURus | - |
|
SCP30S3.3-DNAC/DC DIN RAIL SUPPLY 3.3V 20W |
4,967 |
|
规格书 |
SCP (30W) | Bulk | Discontinued at Digi-Key | AC or DC | 1 | 85 ~ 264 VAC | 100V | 375V | 3.3V | - | - | - | - | - | 6A | 20W | - | ITE (Commercial) | 62% | -25°C ~ 65°C | IP20, Universal Input | CE, cURus | - |
|
|
78.2E.1.230.2414AC/DC DIN RAIL SUPPLY 24V 240W |
3,736 |
|
- |
78 | Box | Active | AC or DC | 1 | 88 ~ 265 VAC | 90V | 275V | 24V | - | - | - | - | - | 10A | 240W | 2.5 kV | ITE (Commercial) | 93% | -20°C ~ 70°C (With Derating) | Adjustable Output, IP20 | CE, cULus, EAC | - |
|
|
SCP30S48B-DNAC/DC DIN RAIL SUPPLY 48V 29W |
1,431 |
|
- |
SCP (30W) | Bulk | Discontinued at Digi-Key | AC or DC | 1 | 85 ~ 264 VAC | 100V | 375V | 48V | - | - | - | - | - | 600mA | 29W | - | ITE (Commercial) | 77% | -25°C ~ 65°C | IP20, Universal Input | CE, cURus | - |
|
LDW240-48PAC/DC DIN RAIL SUPPLY 48V 240W |
2,781 |
|
规格书 |
LDW240 (240W) | Box | Obsolete | AC or DC | 1 | 187 ~ 550 VAC (1 ~ 2 Phase) | 250V | 725V | 48V | - | - | - | - | - | 5A | 240W | 4.2 kV | ITE (Commercial) | 91% | -40°C ~ 70°C (With Derating) | Adjustable Output, IP20, Load Sharing | - | - |
|
|
S8VS-09024SAC/DC DIN RAIL SUPPLY 24V 90W |
1,696 |
|
规格书 |
S8VS (90W) | Bulk | Obsolete | AC | 1 | 100 ~ 240 VAC | - | - | 24V | - | - | - | - | - | 3.75A | 90W | 3 kV | ITE (Commercial) | 80% | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | CE, cULus, cURus, VDE | - |
|
|
S8VS-09024S-FAC/DC DIN RAIL SUPPLY 24V 90W |
3,138 |
|
规格书 |
S8VS (90W) | Bulk | Obsolete | AC | 1 | 100 ~ 240 VAC | - | - | 24V | - | - | - | - | - | 3.75A | 90W | 3 kV | ITE (Commercial) | 80% | -10°C ~ 60°C (With Derating) | Adjustable Output, Universal Input | CE, cULus, cURus, VDE | - |
|
8951350000AC/DC DIN RAIL SUPPLY 24V 180W |
1,604 |
|
规格书 |
Connect Power Pro-M (180W) | Box | Obsolete | AC | 1 | 85 ~ 264 VAC | - | - | 24V | - | - | - | - | - | 7.5A | 180W | 4 kV | ITE (Commercial) | 91% | -25°C ~ 70°C (With Derating) | Adjustable Output, IP20, Load Sharing, Universal Input | CE, cULus, cURus, GOST, TUV | - |
|
CS5.244AC/DC DIN RAIL SUPPLY 24V 120W |
1,604 |
|
规格书 |
DIMENSION C (120W) | Box | Active | AC | 1 | 180 ~ 264 VAC, 264 ~ 300 VAC | 264V | 300V | 24V | - | - | - | - | - | 5A | 120W | 500 V | ITE (Commercial) | 90.2% | -25°C ~ 70°C (With Derating) | Adjustable Output, Load Sharing | ABS, CSA, DNV GL, EAC, IEC, UL | Class I Div 2; 508; 60950-1; 61010-2-201 |
|
|
20800003124AC/DC DIN RAIL SUPPLY 24V 120W |
2,210 |
|
- |
- | Bulk | Obsolete | AC | 1 | 85 ~ 264 VAC | - | - | 24V | - | - | - | - | - | 5A | 120W | - | ITE (Commercial) | 89% | -10°C ~ 70°C | Adjustable Output, Universal Input | - | - |
|
|
20800003125AC/DC DIN RAIL SUPPLY 48V 120W |
1,236 |
|
- |
- | Bulk | Obsolete | AC | 1 | 85 ~ 264 VAC | - | - | 48V | - | - | - | - | - | 3A | 120W | - | ITE (Commercial) | 90% | -10°C ~ 70°C | Adjustable Output, Universal Input | - | - |
|
|
2787-2144/000-070PSU, PRO 2 1-PH |
2,554 |
|
规格书 |
- | Bulk | Active | AC or DC | 1 | 90 ~ 264 VAC | 130V | 240V | 24V | - | - | - | - | - | 5A | 120W | 3.15 kV | Laboratory | 93.8% | -25°C ~ 70°C | Adjustable Output, IP20, PFC, Universal Input | UL | 61010-1 |
|
787-602AC/DC DIN RAIL SUPPLY 24V |
4,060 |
|
规格书 |
- | Box | Obsolete | AC or DC | 1 | 90 ~ 264 VAC | 130V | 300V | 24V | - | - | - | - | - | 1.3A | - | 4.242 kV | Industrial, ITE (Commercial) | 83% | -10°C ~ 70°C | Adjustable Output, IP20, PFC, Universal Input | cURus, EAC, UL | 60950-1; UL 508 |
|
VHK75W-Q24-S3R3-DINDC/DC DIN RAIL SUPPLY 3.3V 75W |
3,639 |
|
规格书 |
VHK75W-DIN (75W) | Box | Active | DC | 1 | - | 9V | 36V | 3.3V | - | - | - | - | - | 15A | 75W | - | - | 77% | -40°C ~ 85°C | - | CE | - |
|
|
VHK75W-Q24-S5-DINDC/DC DIN RAIL SUPPLY 5V 75W |
1,015 |
|
规格书 |
VHK75W-DIN (75W) | Box | Active | DC | 1 | - | 9V | 36V | 5V | - | - | - | - | - | 15A | 75W | - | - | 80% | -40°C ~ 85°C | - | CE | - |
|
|
VHK75W-Q24-S15-DINDC/DC DIN RAIL SUPPLY 15V 75W |
1,158 |
|
规格书 |
VHK75W-DIN (75W) | Box | Active | DC | 1 | - | 9V | 36V | 15V | - | - | - | - | - | 5A | 75W | - | - | 82.5% | -40°C ~ 85°C | - | CE | - |
|
|
VHK75W-Q24-S48-DINDC/DC DIN RAIL SUPPLY 48V 75W |
1,748 |
|
规格书 |
VHK75W-DIN (75W) | Box | Active | DC | 1 | - | 9V | 36V | 48V | - | - | - | - | - | 1.56A | 75W | - | - | 80% | -40°C ~ 85°C | - | CE | - |
|
|
VHK75W-Q48-S3R3-DINDC/DC DIN RAIL SUPPLY 3.3V 75W |
4,265 |
|
规格书 |
VHK75W-DIN (75W) | Box | Active | DC | 1 | - | 18V | 75V | 3.3V | - | - | - | - | - | 15A | 75W | - | - | 78% | -40°C ~ 85°C | - | CE | - |
