购物车固定电感器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 封装/外壳 | 包装 | 产品状态 | 类型 | 材料 - 芯 | 电感 | 容差 | 电流额定值（安培） | 饱和电流 (Isat) | 屏蔽 | 直流电阻 (DCR) | 品质因数 (Q) @ 频率 | 频率 - 自谐振 | 额定值 | 工作温度 | 电感频率 - 测试 | 特性 | 安装类型 | 供应商设备封装 | 尺寸 / 尺寸 | 高度 - 安装后（最大值） |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CTEP105HF-3R0M3.00UH SMD SHLDED POWER INDUCTOR Central Technologies |
2,093 |
|
规格书 |
CTEP105HF | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 3 µH | ±20% | 7.2 A | 12.6A | Shielded | 23.8mOhm Max | - | - | - | -30°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.220" (5.60mm) |
|
|
CTEP105HF-R30N0.30UH SMD SHLDED POWER INDUCTOR Central Technologies |
3,892 |
|
规格书 |
CTEP105HF | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 300 nH | ±30% | 18.8 A | 40A | Shielded | 3.2mOhm Max | - | - | - | -30°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.220" (5.60mm) |
|
|
CTEP105HF-2R5M2.50UH SMD SHLDED POWER INDUCTOR Central Technologies |
1,309 |
|
规格书 |
CTEP105HF | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 2.5 µH | ±20% | 7.8 A | 14A | Shielded | 18mOhm Max | - | - | - | -30°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.220" (5.60mm) |
|
|
CTEP105HF-R80M0.80UH SMD SHLDED POWER INDUCTOR Central Technologies |
1,871 |
|
规格书 |
CTEP105HF | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 800 nH | ±20% | 13.5 A | 25.2A | Shielded | 5.3mOhm Max | - | - | - | -30°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.220" (5.60mm) |
|
|
CTEP105HF-R50M0.50UH SMD SHLDED POWER INDUCTOR Central Technologies |
4,428 |
|
规格书 |
CTEP105HF | Nonstandard | Tape & Reel (TR) | Active | Wirewound | - | 500 nH | ±20% | 15 A | 30.4A | Shielded | 4.1mOhm Max | - | - | - | -30°C ~ 100°C | 100 kHz | - | Surface Mount | - | 0.409" L x 0.409" W (10.40mm x 10.40mm) | 0.220" (5.60mm) |
|
CT181LYF-103JRAD LEADED FIXED SHLDED INDUCTOR Central Technologies |
3,528 |
|
规格书 |
ct181lyf | - | Bulk | Active | - | - | 10 mH | ±5% | - | - | - | 12Ohm | - | 250kHz | - | -20°C ~ 125°C | - | - | Through Hole | - | - | - |
|
|
CT181LYF-472KRAD LEADED FIXED SHLDED INDUCTOR Central Technologies |
4,275 |
|
规格书 |
ct181lyf | - | Bulk | Active | - | - | 4.7 mH | ±10% | - | - | - | 7.5Ohm | - | 380kHz | - | -20°C ~ 125°C | - | - | Through Hole | - | - | - |
|
CTXAL4020F-2R2MHIGH CURRENT SMD POWER INDUCTOR Central Technologies |
4,932 |
|
规格书 |
CTXAL4020F | Nonstandard | Tape & Reel (TR) | Active | - | - | 2.2 µH | ±20% | 5.6 A | 6A | Shielded | 38.7mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 0.083" (2.10mm) |
|
|
CTXAL4020F-R22MHIGH CURRENT SMD POWER INDUCTOR Central Technologies |
3,646 |
|
规格书 |
CTXAL4020F | Nonstandard | Tape & Reel (TR) | Active | - | - | 220 nH | ±20% | 16.8 A | 18.8A | Shielded | 4.6mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 0.083" (2.10mm) |
|
|
CTXAL4020F-1R0MHIGH CURRENT SMD POWER INDUCTOR Central Technologies |
2,433 |
|
规格书 |
CTXAL4020F | Nonstandard | Tape & Reel (TR) | Active | - | - | 1 µH | ±20% | 9.6 A | 8.8A | Shielded | 14.6mOhm Max | - | - | - | -40°C ~ 125°C | 100 kHz | - | Surface Mount | - | 0.161" L x 0.161" W (4.10mm x 4.10mm) | 0.083" (2.10mm) |
