购物车汽车继电器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 线圈类型 | 线圈电流 | 线圈电压 | 触点形式 | 触点额定值（电流） | 切换电压 | 必须动作电压 | 必须释放电压 | 动作时间 | 释放时间 | 特性 | 安装类型 | 端接样式 | 工作温度 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
CM1-D-24VRELAY AUTOMOTIVE SPDT 15A 24V |
4,094 |
|
规格书 |
CM | Bulk | Obsolete | Non Latching | 75 mA | 24VDC | SPDT (1 Form C) | 15 A | 28VDC - Nom | 14 VDC | 2.4 VDC | 10 ms | 15 ms | Diode, Sealed - Fully | Socketable | Plug In | -40°C ~ 85°C |
|
CM1-D-P-12VRELAY AUTOMOTIVE SPDT 35A 12V |
1,978 |
|
规格书 |
CM | Bulk | Obsolete | Non Latching | 125 mA | 12VDC | SPDT (1 Form C) | 35 A | 14VDC - Nom | 7 VDC | 1.2 VDC | 10 ms | 15 ms | Diode, Sealed - Fully | Through Hole | PC Pin | -40°C ~ 85°C |
|
CM1-P-12VRELAY AUTOMOTIVE SPDT 35A 12V |
4,607 |
|
规格书 |
CM | Bulk | Obsolete | Non Latching | 125 mA | 12VDC | SPDT (1 Form C) | 35 A | 14VDC - Nom | 7 VDC | 1.2 VDC | 10 ms | 10 ms | Sealed - Fully | Through Hole | PC Pin | -40°C ~ 85°C |
|
|
CM1-R-P-12VRELAY AUTOMOTIVE SPDT 35A 12V |
4,100 |
|
规格书 |
CM | Bulk | Obsolete | Non Latching | 125 mA | 12VDC | SPDT (1 Form C) | 35 A | 14VDC - Nom | 7 VDC | 1.2 VDC | 10 ms | 10 ms | Resistor, Sealed - Fully | Through Hole | PC Pin | -40°C ~ 85°C |
|
|
CM1A-D-12VRELAY AUTOMOTIVE SPST 35A 12V |
1,680 |
|
规格书 |
CM | Bulk | Obsolete | Non Latching | 125 mA | 12VDC | SPST-NO (1 Form A) | 35 A | 14VDC - Nom | 7 VDC | 1.2 VDC | 10 ms | 15 ms | Diode, Sealed - Fully | Socketable | Plug In | -40°C ~ 85°C |
|
|
CM1A-P-12VRELAY AUTOMOTIVE SPST 35A 12V |
3,100 |
|
规格书 |
CM | Bulk | Obsolete | Non Latching | 125 mA | 12VDC | SPST-NO (1 Form A) | 35 A | 14VDC - Nom | 7 VDC | 1.2 VDC | 10 ms | 10 ms | Sealed - Fully | Through Hole | PC Pin | -40°C ~ 85°C |
|
|
CM1A-R-P-12VRELAY AUTOMOTIVE SPST 35A 12V |
1,463 |
|
规格书 |
CM | Bulk | Obsolete | Non Latching | 125 mA | 12VDC | SPST-NO (1 Form A) | 35 A | 14VDC - Nom | 7 VDC | 1.2 VDC | 10 ms | 10 ms | Resistor, Sealed - Fully | Through Hole | PC Pin | -40°C ~ 85°C |
|
|
CM1AF-D-12VRELAY AUTOMOTIVE SPST 35A 12V |
1,015 |
|
规格书 |
CM | Bulk | Obsolete | Non Latching | 125 mA | 12VDC | SPST-NO (1 Form A) | 35 A | 14VDC - Nom | 7 VDC | 1.2 VDC | 10 ms | 15 ms | Diode, Sealed - Flux Protection | Socketable | Plug In | -40°C ~ 85°C |
|
|
CM1F-D-12VRELAY AUTOMOTIVE SPDT 35A 12V |
3,686 |
|
规格书 |
CM | Bulk | Obsolete | Non Latching | 125 mA | 12VDC | SPDT (1 Form C) | 35 A | 14VDC - Nom | 7 VDC | 1.2 VDC | 10 ms | 15 ms | Diode, Sealed - Flux Protection | Socketable | Plug In | -40°C ~ 85°C |
|
|
CM1F-D-24VRELAY AUTOMOTIVE SPDT 15A 24V |
2,385 |
|
规格书 |
CM | Tube | Obsolete | Non Latching | 75 mA | 24VDC | SPDT (1 Form C) | 15 A | 28VDC - Nom | 14 VDC | 2.4 VDC | 10 ms | 15 ms | Diode, Sealed - Flux Protection | Socketable | Plug In | -40°C ~ 85°C |
|
|
CM1F-D-P-12VRELAY AUTOMOTIVE SPDT 35A 12V |
3,868 |
|
规格书 |
CM | Bulk | Obsolete | Non Latching | 125 mA | 12VDC | SPDT (1 Form C) | 35 A | 14VDC - Nom | 7 VDC | 1.2 VDC | 10 ms | 15 ms | Diode, Sealed - Flux Protection | Through Hole | PC Pin | -40°C ~ 85°C |
|
|
CM1F-P-12VRELAY AUTOMOTIVE SPDT 35A 12V |
3,184 |
|
规格书 |
CM | Bulk | Obsolete | Non Latching | 125 mA | 12VDC | SPDT (1 Form C) | 35 A | 14VDC - Nom | 7 VDC | 1.2 VDC | 10 ms | 10 ms | Sealed - Flux Protection | Through Hole | PC Pin | -40°C ~ 85°C |
|
CQ1-12VRELAY AUTOMOTIVE SPDT 20A 12V |
3,319 |
|
规格书 |
CQ | Tube | Obsolete | Non Latching | 53.3 mA | 12VDC | SPDT (1 Form C) | 20 A | 14VDC - Nom | 7.2 VDC | 1 VDC | 10 ms | 10 ms | Sealed - Fully | Through Hole | PC Pin | -40°C ~ 85°C |
|
CR2-12VRELAY AUTOMOTIVE SPDT 20A 12V |
2,041 |
|
规格书 |
CR | Bulk | Obsolete | Non Latching | 53.3 mA | 12VDC | SPDT (1 Form C) x 2 | 20 A | 14VDC - Nom | 7.2 VDC | 1 VDC | 10 ms | 10 ms | Sealed - Fully | Through Hole | PC Pin | -40°C ~ 85°C |
|
JSM1-9V-4RELAY AUTOMOTIVE SPDT 10A 9V |
3,249 |
|
规格书 |
JS-M | Bulk | Obsolete | Non Latching | 71.4 mA | 9VDC | SPDT (1 Form C) | 10 A | 16VDC - Max | 4.7 VDC | 0.7 VDC | 10 ms | 10 ms | Sealed - Fully | Through Hole | PC Pin | -40°C ~ 85°C |
|
|
JSM1A-12V-4RELAY AUTOMOTIVE SPST 10A 12V |
1,121 |
|
规格书 |
JS-M | Tube | Obsolete | Non Latching | 53.3 mA | 12VDC | SPST-NO (1 Form A) | 10 A | 16VDC - Max | 6.3 VDC | 0.9 VDC | 10 ms | 10 ms | Sealed - Fully | Through Hole | PC Pin | -40°C ~ 85°C |
|
|
JSM1A-12V-5RELAY AUTOMOTIVE SPST 15A 12V |
2,859 |
|
规格书 |
JS-M | Bulk | Obsolete | Non Latching | 53.3 mA | 12VDC | SPST-NO (1 Form A) | 15 A | 16VDC - Max | 6.3 VDC | 0.9 VDC | 10 ms | 10 ms | Sealed - Fully | Through Hole | PC Pin | -40°C ~ 85°C |
|
|
JSM1A-9V-4RELAY AUTOMOTIVE SPST 10A 9V |
1,932 |
|
规格书 |
JS-M | Bulk | Obsolete | Non Latching | 71.4 mA | 9VDC | SPST-NO (1 Form A) | 10 A | 16VDC - Max | 4.7 VDC | 0.7 VDC | 10 ms | 10 ms | Sealed - Fully | Through Hole | PC Pin | -40°C ~ 85°C |
|
|
JSM1A-9V-5RELAY AUTOMOTIVE SPST 15A 9V |
4,085 |
|
规格书 |
JS-M | Bulk | Obsolete | Non Latching | 71.4 mA | 9VDC | SPST-NO (1 Form A) | 15 A | 16VDC - Max | 4.7 VDC | 0.7 VDC | 10 ms | 10 ms | Sealed - Fully | Through Hole | PC Pin | -40°C ~ 85°C |
|
|
JSM1AF-12V-4RELAY AUTOMOTIVE SPST 10A 12V |
1,627 |
|
规格书 |
JS-M | Bulk | Obsolete | Non Latching | 53.3 mA | 12VDC | SPST-NO (1 Form A) | 10 A | 16VDC - Max | 6.3 VDC | 0.9 VDC | 10 ms | 10 ms | Sealed - Flux Protection | Through Hole | PC Pin | -40°C ~ 85°C |
