购物车交流直流转换器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输入 | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 电压 - 输出 4 | 电压 - 输出 5 | 电压 - 输出 6 | 电流 - 输出 1 | 电流 - 输出 2 | 电流 - 输出 3 | 电流 - 输出 4 | 电流 - 输出 5 | 电流 - 输出 6 | 功率（瓦特） | 应用 | 电压 - 隔离 | 工作温度 | 特性 | 安装类型 | 尺寸 / 尺寸 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
VS150E-5AC/DC CONVERTER 5V 150W |
3,726 |
|
规格书 |
VSB (150W) | Bulk | Active | Open Frame | 1 | 85 ~ 132 VAC | 5V | - | - | - | - | - | 30 A | - | - | - | - | - | 150W | ITE (Commercial) | 2.5 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable | Chassis Mount | 8.74" L x 2.95" W x 1.42" H (222.0mm x 75.0mm x 36.0mm) |
|
|
ZWS150BP-24/LAC/DC CONVERTER 24V 150W |
4,268 |
|
规格书 |
ZWS-BP (150W) | Bulk | Active | Open Frame | 1 | 85 ~ 265 VAC | 24V | - | - | - | - | - | 6.3 A | - | - | - | - | - | 150W | ITE (Commercial) | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 6.30" L x 2.95" W x 1.46" H (160.0mm x 75.0mm x 37.0mm) |
|
|
ZWS150BP-36/TAC/DC CONVERTER 36V 150W |
1,163 |
|
规格书 |
ZWS-BP (150W) | Bulk | Active | Open Frame | 1 | 85 ~ 265 VAC | 36V | - | - | - | - | - | 4.2 A | - | - | - | - | - | 150W | ITE (Commercial) | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 6.30" L x 2.95" W x 1.46" H (160.0mm x 75.0mm x 37.0mm) |
|
|
ZWS150BP-36/TLAC/DC CONVERTER 36V 150W |
4,011 |
|
规格书 |
ZWS-BP (150W) | Bulk | Active | Open Frame | 1 | 85 ~ 265 VAC | 36V | - | - | - | - | - | 4.2 A | - | - | - | - | - | 150W | ITE (Commercial) | 3 kV | -10°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, Load Sharing, PFC, Universal Input | Chassis Mount | 6.30" L x 2.95" W x 1.46" H (160.0mm x 75.0mm x 37.0mm) |
|
LEA100F-12AC/DC CONVERTER 12V 100W |
3,565 |
|
规格书 |
LEA (100W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC | 12V | - | - | - | - | - | 8.5 A | - | - | - | - | - | 100W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 8.74" L x 2.44" W x 1.26" H (222.0mm x 62.0mm x 32.0mm) |
|
|
LEA100F-24-SNAC/DC CONVERTER 24V 100W |
4,794 |
|
规格书 |
LEA (100W) | Box | Obsolete | Enclosed | 1 | 85 ~ 264 VAC | 24V | - | - | - | - | - | 4.3 A | - | - | - | - | - | 100W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 8.74" L x 2.44" W x 1.26" H (222.0mm x 62.0mm x 32.0mm) |
|
|
LEA100F-48-SNAC/DC CONVERTER 48V 100W |
4,277 |
|
规格书 |
LEA (100W) | Box | Obsolete | Enclosed | 1 | 85 ~ 264 VAC | 48V | - | - | - | - | - | 2.2 A | - | - | - | - | - | 100W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 8.74" L x 2.44" W x 1.26" H (222.0mm x 62.0mm x 32.0mm) |
|
LEA150F-24AC/DC CONVERTER 24V 150W |
2,001 |
|
规格书 |
LEA (150W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC | 24V | - | - | - | - | - | 6.3 A | - | - | - | - | - | 150W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 8.74" L x 2.95" W x 1.46" H (222.0mm x 75.0mm x 37.0mm) |
|
LEA50F-12AC/DC CONVERTER 12V 50W |
4,176 |
|
规格书 |
LEA (50W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC | 12V | - | - | - | - | - | 4.3 A | - | - | - | - | - | 50W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 7.68" L x 2.17" W x 0.91" H (195.0mm x 55.0mm x 23.0mm) |
|
|
LEA50F-24AC/DC CONVERTER 24V 50W |
1,878 |
|
规格书 |
LEA (50W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC | 24V | - | - | - | - | - | 2.1 A | - | - | - | - | - | 50W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 7.68" L x 2.17" W x 0.91" H (195.0mm x 55.0mm x 23.0mm) |
|
|
LEA50F-48AC/DC CONVERTER 48V 50W |
3,861 |
|
规格书 |
LEA (50W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC | 48V | - | - | - | - | - | 1.1 A | - | - | - | - | - | 50W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 7.68" L x 2.17" W x 0.91" H (195.0mm x 55.0mm x 23.0mm) |
|
LEA75F-12-SNAC/DC CONVERTER 12V 75W |
4,673 |
|
规格书 |
LEA (75W) | Box | Obsolete | Enclosed | 1 | 85 ~ 264 VAC | 12V | - | - | - | - | - | 6.3 A | - | - | - | - | - | 75W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | PFC, Universal Input | Chassis Mount | 8.74" L x 2.17" W x 1.14" H (222.0mm x 55.0mm x 29.0mm) |
|
LEP100F-48AC/DC CONVERTER 48V 100W |
2,782 |
|
规格书 |
LEP (100W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC | 48V | - | - | - | - | - | 2.1 A | - | - | - | - | - | 100W | ITE (Commercial) | 3 kV | -10°C ~ 70°C (With Derating) | DC Input Capable, Universal Input | Chassis Mount | 8.74" L x 2.95" W x 1.38" H (222.0mm x 74.9mm x 35.1mm) |
|
LEP150F-24AC/DC CONVERTER 24V 150W |
2,892 |
|
规格书 |
LEP (150W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC | 24V | - | - | - | - | - | 6.3 A | - | - | - | - | - | 150W | ITE (Commercial) | 3 kV | -10°C ~ 70°C (With Derating) | DC Input Capable, Universal Input | Chassis Mount | 8.74" L x 3.35" W x 1.57" H (222.0mm x 85.1mm x 39.9mm) |
|
LEP150F-48-SNAC/DC CONVERTER 48V 150W |
1,113 |
|
规格书 |
LEP (150W) | Box | Obsolete | Enclosed | 1 | 85 ~ 264 VAC | 48V | - | - | - | - | - | 3.2 A | - | - | - | - | - | 150W | ITE (Commercial) | 3 kV | -10°C ~ 70°C (With Derating) | DC Input Capable, Universal Input | Chassis Mount | 8.74" L x 3.35" W x 1.57" H (222.0mm x 85.1mm x 39.9mm) |
|
|
LEA100F-12-YAC/DC CONVERTER 12V 100W |
3,889 |
|
规格书 |
LEA (100W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC | 12V | - | - | - | - | - | 8.5 A | - | - | - | - | - | 100W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 8.74" L x 2.44" W x 1.26" H (222.0mm x 62.0mm x 32.0mm) |
|
|
LEA100F-15AC/DC CONVERTER 15V 100W |
3,107 |
|
规格书 |
LEA (100W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC | 15V | - | - | - | - | - | 6.7 A | - | - | - | - | - | 100W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 8.74" L x 2.44" W x 1.26" H (222.0mm x 62.0mm x 32.0mm) |
|
|
LEA100F-15-SNAC/DC CONVERTER 15V 100W |
2,867 |
|
规格书 |
LEA (100W) | Box | Obsolete | Enclosed | 1 | 85 ~ 264 VAC | 15V | - | - | - | - | - | 6.7 A | - | - | - | - | - | 100W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 8.74" L x 2.44" W x 1.26" H (222.0mm x 62.0mm x 32.0mm) |
|
|
LEA100F-24-HAC/DC CONVERTER 24V 100W |
4,015 |
|
规格书 |
LEA (100W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC | 24V | - | - | - | - | - | 4.3 A | - | - | - | - | - | 100W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 8.74" L x 2.44" W x 1.26" H (222.0mm x 62.0mm x 32.0mm) |
|
|
LEA100F-24-HYAC/DC CONVERTER 24V 100W |
2,477 |
|
规格书 |
LEA (100W) | Box | Obsolete | Open Frame | 1 | 85 ~ 264 VAC | 24V | - | - | - | - | - | 4.3 A | - | - | - | - | - | 100W | ITE (Commercial) | 3 kV | -20°C ~ 70°C (With Derating) | Adjustable Output, Universal Input | Chassis Mount | 8.74" L x 2.44" W x 1.26" H (222.0mm x 62.0mm x 32.0mm) |
