购物车交流直流转换器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输入 | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 电压 - 输出 4 | 电压 - 输出 5 | 电压 - 输出 6 | 电流 - 输出 1 | 电流 - 输出 2 | 电流 - 输出 3 | 电流 - 输出 4 | 电流 - 输出 5 | 电流 - 输出 6 | 功率（瓦特） | 应用 | 电压 - 隔离 | 工作温度 | 特性 | 安装类型 | 尺寸 / 尺寸 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AMEOF120-15SHAMJZ-BAC/DC CONVERTER 15V 114W aimtec |
4,990 |
|
规格书 |
AMEOF120-HAMJZ (114W) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC, 120 ~ 370 VDC | 15V | - | - | - | - | - | 7.6 A | - | - | - | - | - | 114W | Household Appliances, ITE (Commercial), Medical | 4 kV | -40°C ~ 85°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Universal Input | Chassis Mount | 3.00" L x 2.00" W x 1.22" H (76.2mm x 50.8mm x 31.0mm) |
|
AMEOF45-12SHAMJZ-BAC/DC CONVERTER 10.2V 13.8V 45W aimtec |
4,685 |
|
规格书 |
AMEOF45-HAMJZ (45W) | Tube | Active | Enclosed | 2 | 80 ~ 264 VAC | 10.2V | 13.8V | - | - | - | - | - | - | - | - | - | - | 45W | Industrial, ITE (Commercial), Medical | - | -40°C ~ 85°C (With Derating) | - | Chassis Mount | 2.00" L x 1.04" W x 3.00" H (50.8mm x 26.4mm x 76.2mm) |
|
AMEOF225-27SHAMJZ-BAC/DC CONVERTER 27V 130W aimtec |
3,354 |
|
规格书 |
AMEOF225-HAMJZ (130W ) | Box | Active | Open Frame | 1 | 85 ~ 264 VAC, 120 ~ 373 VDC | 27V | - | - | - | - | - | 8.35 A | - | - | - | - | - | 130W (225W Forced Air) | Household Appliances, ITE (Commercial), Medical | 4 kV | -40°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Universal Input | Chassis Mount | 4.00" L x 2.00" W x 1.00" H (101.6mm x 50.8mm x 25.4mm) |
|
|
AMEOF45-24SHAMJZ-FAC/DC CONVERTER 21.6V 28.5V 65W aimtec |
1,715 |
|
规格书 |
AMEOF45-HAMJZ (65W) | Tube | Active | Enclosed | 2 | 80 ~ 264 VAC | 21.6V | 28.5V | - | - | - | - | - | - | - | - | - | - | 65W | Industrial, ITE (Commercial), Medical | - | -40°C ~ 85°C (With Derating) | - | Chassis Mount | 2.38" L x 1.31" W x 3.60" H (60.5mm x 33.3mm x 91.4mm) |
|
|
AMEOF45-24SHAMJZ-F-BAC/DC CONVERTER 21.6V 28.5V 65W aimtec |
1,427 |
|
规格书 |
AMEOF45-HAMJZ (65W) | Tube | Active | Enclosed | 2 | 80 ~ 264 VAC | 21.6V | 28.5V | - | - | - | - | - | - | - | - | - | - | 65W | Industrial, ITE (Commercial), Medical | - | -40°C ~ 85°C (With Derating) | - | Chassis Mount | 2.38" L x 1.31" W x 3.60" H (60.5mm x 33.3mm x 91.4mm) |
|
AMEOF120-48SHAMJZ-F-BAC/DC CONVERTER 45.6V 50.4V 120W aimtec |
1,594 |
|
规格书 |
AMEOF120-HAMJZ (120W) | Case | Active | Enclosed | 2 | 85 ~ 264 VAC | 45.6V | 50.4V | - | - | - | - | - | - | - | - | - | - | 120W | Industrial, ITE (Commercial), Medical | - | -40°C ~ 85°C (With Derating) | - | Chassis Mount | 2.44" L x 1.58" W x 3.15" H (62.0mm x 40.1mm x 80.0mm) |
|
|
AMEOF120-24SHAMJZ-F-BAC/DC CONVERTER 22.8V 25.2V 120W aimtec |
2,689 |
|
规格书 |
AMEOF120-HAMJZ (120W) | Case | Active | Enclosed | 2 | 85 ~ 264 VAC | 22.8V | 25.2V | - | - | - | - | - | - | - | - | - | - | 120W | Industrial, ITE (Commercial), Medical | - | -40°C ~ 85°C (With Derating) | - | Chassis Mount | 2.44" L x 1.58" W x 3.15" H (62.0mm x 40.1mm x 80.0mm) |
|
AMEOF450-36SHAMJZAC/DC CONVERTER 34.2V 37.8V 450W aimtec |
2,230 |
|
规格书 |
AMEOF450-HAMJZ (450W) | Case | Active | Open Frame | 2 | 90 ~ 264 VAC | 34.2V | 37.8V | - | - | - | - | - | - | - | - | - | - | 450W | Industrial, ITE (Commercial), Medical | - | -40°C ~ 70°C (With Derating) | - | Chassis Mount | 3.00" L x 1.52" W x 5.00" H (76.2mm x 38.6mm x 127.0mm) |
|
|
AMEOF450-36SHAMJZ-FBAC/DC CONVERTER 34.2V 37.8V 450W aimtec |
3,037 |
|
规格书 |
AMEOF450-HAMJZ (450W) | Case | Active | Enclosed | 2 | 90 ~ 264 VAC | 34.2V | 37.8V | - | - | - | - | - | - | - | - | - | - | 450W | Industrial, ITE (Commercial), Medical | - | -40°C ~ 70°C (With Derating) | - | Chassis Mount | 3.39" L x 1.70" W x 6.30" H (86.1mm x 43.2mm x 160.0mm) |
