购物车交流直流转换器
| 图片 | 型号 | 库存 | 数量 | 规格书 | 系列 | 包装 | 产品状态 | 类型 | 输出数量 | 电压 - 输入 | 电压 - 输出 1 | 电压 - 输出 2 | 电压 - 输出 3 | 电压 - 输出 4 | 电压 - 输出 5 | 电压 - 输出 6 | 电流 - 输出 1 | 电流 - 输出 2 | 电流 - 输出 3 | 电流 - 输出 4 | 电流 - 输出 5 | 电流 - 输出 6 | 功率（瓦特） | 应用 | 电压 - 隔离 | 工作温度 | 特性 | 安装类型 | 尺寸 / 尺寸 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AQF700-48SAC/DC CONVERTER 48V 700W ARCH Electronics Corp |
2,650 |
|
规格书 |
AQF700 (700W) | Box | Active | Enclosed | 1 | 90 ~ 264 VAC | 48V | - | - | - | - | - | 14.58 A | - | - | - | - | - | 700W | ITE (Commercial) | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote On/Off, Standby Output, Universal Input | Chassis Mount | 6.70" L x 3.66" W x 1.61" H (170.2mm x 93.0mm x 40.9mm) |
|
|
AQF700-24SAC/DC CONVERTER 24V 700W ARCH Electronics Corp |
3,529 |
|
规格书 |
AQF700 (700W) | Box | Active | Enclosed | 1 | 90 ~ 264 VAC | 24V | - | - | - | - | - | 29.16 A | - | - | - | - | - | 700W | ITE (Commercial) | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote On/Off, Standby Output, Universal Input | Chassis Mount | 6.70" L x 3.66" W x 1.61" H (170.2mm x 93.0mm x 40.9mm) |
|
ARF240E-24SAC/DC CONVERTER 24V 240W ARCH Electronics Corp |
4,699 |
|
- |
ARF240E (240W) | Box | Active | Enclosed | 1 | 90 ~ 264 VAC | 24V | - | - | - | - | - | 10 A | - | - | - | - | - | 240W | ITE (Commercial) | 4 kV | -30°C ~ 80°C (With Derating) | Adjustable Output, PFC, Universal Input | Chassis Mount | 4.10" L x 2.46" W x 1.54" H (104.1mm x 62.5mm x 39.1mm) |
|
ARF130U-24SAC/DC CONVERTER 24V 120W ARCH Electronics Corp |
3,909 |
|
规格书 |
ARF130U (130W) | Box | Active | Open Frame | 1 | 90 ~ 264 VAC | 24V | - | - | - | - | - | 5.417 A | - | - | - | - | - | 120W (130W Forced Air) | ITE (Commercial) | 4 kV | -30°C ~ 80°C (With Derating) | Adjustable Output, PFC, Universal Input | Chassis Mount | 3.15" L x 2.35" W x 1.50" H (80.0mm x 59.7mm x 38.1mm) |
|
ARF500E-24SAC/DC CONVERTER 24V 499W ARCH Electronics Corp |
4,445 |
|
规格书 |
ARF500E (500W) | Box | Active | Enclosed | 1 | 90 ~ 264 VAC, 127 ~ 370 VDC | 24V | - | - | - | - | - | 20.8 A | - | - | - | - | - | 499W | ITE (Commercial) | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, DC Input Capable, PFC, Remote On/Off, Remote Sense, Standby Output, Universal Input | Chassis Mount | 5.11" L x 3.25" W x 2.45" H (129.8mm x 82.6mm x 62.2mm) |
|
|
AQF700-28SAC/DC CONVERTER 28V 700W ARCH Electronics Corp |
1,501 |
|
规格书 |
AQF700 (700W) | Box | Active | Enclosed | 1 | 90 ~ 264 VAC | 28V | - | - | - | - | - | 25 A | - | - | - | - | - | 700W | ITE (Commercial) | 4 kV | -30°C ~ 70°C (With Derating) | Adjustable Output, PFC, Remote On/Off, Standby Output, Universal Input | Chassis Mount | 6.70" L x 3.66" W x 1.61" H (170.2mm x 93.0mm x 40.9mm) |
|
|
ARF240E-12SAC/DC CONVERTER 12V 234W ARCH Electronics Corp |
1,171 |
|
- |
ARF240E (240W) | Box | Active | Enclosed | 1 | 90 ~ 264 VAC | 12V | - | - | - | - | - | 20 A | - | - | - | - | - | 234W (240W Forced Air) | ITE (Commercial) | 4 kV | -30°C ~ 80°C (With Derating) | Adjustable Output, PFC, Universal Input | Chassis Mount | 4.10" L x 2.46" W x 1.54" H (104.1mm x 62.5mm x 39.1mm) |
|
ARF240U-24SAC/DC CONVERTER 24V 240W ARCH Electronics Corp |
4,353 |
|
- |
ARF240U (240W) | Box | Active | Open Frame | 1 | 90 ~ 264 VAC | 24V | - | - | - | - | - | 10 A | - | - | - | - | - | 240W | ITE (Commercial) | 4 kV | -30°C ~ 80°C (With Derating) | Adjustable Output, PFC, Universal Input | Chassis Mount | 4.10" L x 2.46" W x 1.54" H (104.1mm x 62.5mm x 39.1mm) |
|
AQF1000-48SAC/DC CONVERTER 48V 1000W ARCH Electronics Corp |
1,305 |
|
规格书 |
AQF1000 (1kW) | Case | Active | Enclosed | 1 | 90 ~ 264 VAC | 48V | - | - | - | - | - | 20.84 A | - | - | - | - | - | 1000W | ITE (Commercial) | 4.3 kV | -20°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 7.66" L x 4.02" W x 1.62" H (194.6mm x 102.1mm x 41.1mm) |
|
|
AQF1000-24SAC/DC CONVERTER 24V 1000W ARCH Electronics Corp |
3,089 |
|
规格书 |
AQF1000 (1kW) | Case | Active | Enclosed | 1 | 90 ~ 264 VAC | 24V | - | - | - | - | - | 41.67 A | - | - | - | - | - | 1000W | ITE (Commercial) | 4.3 kV | -20°C ~ 70°C (With Derating) | Universal Input | Chassis Mount | 7.66" L x 4.02" W x 1.62" H (194.6mm x 102.1mm x 41.1mm) |
